Basic HTML Version
T.I
T.2
T.3
T.4
T.D
T.G
T.7
T.8
T.D
T.IO
T.II
T.12
T.13
T.
TEST MENU
Switch Edges
Switch Levels
Single Switch
Solenoid Test
Flasher Test
General Illumination
Sound
&
Music Test
Single Lamps
All Lamps
Lamp & Flasher Tests
Display Test
Rudy Test
Trap Door Test
T.I Switch Edges
For all switches, the number on the left indicates the column, the number on the right
indicates the row. Example- Switch 23 means 2nd column, 3rd row.
To test the Left and Right Flippers, press the Left or Right Flipper buttons during switch test. The
flipper name and switch number should show in the displays. Any other results indicate the
system has detected a problem with the flipper circuit.
To activat e the Switch Edges Test, from the Test Menu, press the Enter button. The name and
number of each switch that is pressed is shown in the displays. If any other switch, or no switch at
an is indicated, the system has detected a problemwith the switch circuit.
Press Escape to return to the Test Menu. Press the Up button to display the next test, the Switch
Levels Test.
T.2 Switch Levels
Once the test name is shown under the Test Menu, press the Enter button. The name and number of
each switch that is activated is shown in the displays. This test automatically cycles through all
switches that are detected closed.
Press the Escape button to return to the Test Menu .Press the Up button to display the next test, the
Singl e Switch Test .
~.,
FUNHOUSE 1·2B
•
•
•
