No.
WMA486-2
MANUAL AMENDMENT
MANUAL AFFECTED:
FLASH Manual
PURPOSE:
This game uses different software indicated by green-labeled ROMs and PROMs.
Function numbers for game adjustment are sl ightly rearranged from the
earl ier software using yel low-labeled ROMs and PROMs.
CHANGE:
Refer to the attached sheets for game ed
j
us+men+s,
To determine which ROMs and PROMs are in use without inspecting the CPU Board,
observe the Test 04 Function 00 readout. Green-labeled ROMs and PROMs [Part
Nos. 5A 9233 (IC20) and 5A 9234 (IC17»)are indicated by "1486 1" and yellow-
labeled ones [Part Nos. 5A 9196 (IC20) and 5A 9197 (IC17») are indicated by
"0486 1" or "0486 2".
Note that green- and yel low-labeled ROMs and PROMs cannot be intermixed in
a game.
With the new program, Diagnostic Test 02 pulses solenoid 18 with 17 displayed
and pulses solenoid 17 with 18 displayed.
~ CiJfi/tiam4®
~ ELECTRONICa. INC.
An Xcor International Inc .. Company
3401 N. California Ave .. Chicago. II. 6061S
