b. From the game over mode,
(1) Set the AUTO-UP / MANU AL-DOWN switch to
MANU AL-DOWN and momentarily depress the
ADVANCE pushbutton.
(2) Set the switch to AUTO-UP and operate the
ADVANCE pushbutton until 01 is indicated on
the number of credits display.
The multiplexed lights should blink on and off.
2. If no further tests are required, tum the game OFF and
back ON to return to the game over mode.
SOLENOID TEST-TEST 02
This test permits checking of all solenoids by causing the
Driver Board to pulse each solenoid. Refer to Table
3
and
proceed as follows:
I.
Enter the Solenoid Test in one of the following ways:
a. From the Display Digits or Lamp Test, set the
AUTO-UP/MANUAL-DOWN switch to AUTO-
UP and operate the ADVANCE pushbutton until 02
is indicated on the number of credits display.
b. From the game over mode,
(I) Setthe AUTO-UP
j
MANU AL-DOWN switch to
MANU AL-DOWN and momentarily depress the
ADVANCE pushbutton.
(2)
Set the switch to AUTO-UP and operate the
ADVANCE pushbutton until 02 is indicated in
the number of credits display.
The ball in play display should indicate each solenoid
number as it is being pulsed.
2. To repeatedly pulse solenoids one at a time set the switch
to MANUAL-DOWN and momentarily depress the
ADVANCE pushbutton.
The solenoid number
indicated in the ball in play display should be pulsed
repeatedly.
3.
Each time the ADY ANCE pushbutton is depressed, the
next solenoid will be indicated in the ball in play display
and will be pulsed.
4. If no further tests are required, turn the game OFF and
back ON to return to the game over mode.
Table
3.
Solenoids
SOLENOID
NO.
FUNCTION
I
2
3
4
5
6
7
8
9
10
II
12
13
14
15
16
17
18
19
20
21
22
Ball Release
5-Bank (1-3) (Top) Drop Targets
5-Bank (4-5) (Bottom) Drop Targets Reset
3-Bank Drop Targets Reset
Eject Hole
"Flash" Lamps=
Not Used
Not Used
Sound
Sound
Sound
Sound
Sound
Credit Knocker
Not Used
Coin Lockout
Right Jet Bumper
Left Jet Bumper
Lower Jet Bumper
Right Kicker
Left Kicker
Not Used
• The "FLASH" lamps
are lit dimly as part of
normal operation.
18
SWITCH TEST - TEST 03
This test permits checking of all multiplexed switches in the
game. Refer to Figure 8 and proceed as follows:
l. Enter the Switch Test in one of the following ways:
a. From the Display Digits, Lamp, or Solenoid Tests,
set the AUTO-UP/MANUAL-DOWN switch to
AUTO-UP and operate the ADVANCE pushbutton
until 03 is indicated on the number of credits display.
b. From the game over mode,
(1) Set the AUTO-UP/MANUAL-DOWN switch to
MANU AL-DOWN and momentarily depress the
ADVANCE pushbutton.
(2) Set the switch to AUTO-UP and operate the
ADVANCE pushbutton until 03 is indicated on
the number of credits display.
All stuck switches will be sequentially indicated on the ball in
play display. If there are no stuck switches, the display will
be blank.
2.
Actuate each switch and check for the proper switch
number on the ball in play display.
3. If it is desired to change game adjustment or review
game status, refer to Section 3, Game Adjustments.
Otherwise, tum the game OFF and back ON to return to
the game over mode.
AUTO CYCLE MODE
This mode is provided to help diagnose intermittent
problems by continuously performing the Display Digits,
Lamps, and Solenoid Tests. Each cycle of this mode
sequences through the display tests, flashes the lamps 64
times, and pulses each solenoid. This mode is initiated by
using the coin door switches and two switches on the CPU
Board. Refer to Figures 5 and 6 and proceed as follows:
1. With the game in the game over mode, set the AUTO-
UP/MANUAL-DOWN switch to MANUAL-DOWN
and momentarily depress the ADVANCE pushbutton.
All displays should go blank.
2. Remove the backglass and unlatch and open the insert
door.
3.
Set all switches on the MASTER COMMAND slide
switch to OFF (move to the right).
4. Set switch 6 to ON (move to the left).
5. Momentarily depress the MASTER COMMAND
ENTER pushbutton. The LED's should blink once.
6.
Set the AUTO-UPjMANUAL-DOWN switch to
AUTO-UP and momentarily depress the ADVANCE
pushbutton. The Auto Cycle mode should start with the
display digits test.
7. To gain manual control during the Display Digits Test,
momentarily depress the ADVANCE pushbutton with
the toggle switch set to MANUAL-DOWN.
8. To return to the Auto Cycle mode, set the toggle switch
to AUTO-UP and momentarily depress the ADVANCE
pushbutton.
9. To gain manual control during the Solenoid test •
momentarily depress the ADVANCE pushbutton with
the toggle switch set to MANUAL-DOWN.
10. To return to the Auto Cycle mode, set the toggle switch
to AUTO-UP.
