AUX. DRIVER
o
0
A16 Auxiliary Driver-SeR Lamp Flasher
AS-2S18-67
REMOVE -5 PIN-------'
FOR KEY
COMPONENTS PARTS LIST
REFERENCE
BALLY
••
ITEM QTY.
DESIGNATION
D:iSCRIPTION
PART
#
1
1 P-2948-451
PC. Board
M-645-584
2
1 R1
300
n.
5%, 1f4W
E-105-219
3
1 Jl
6 Pin Wafer-KK156
E-736-6
4
1 Ul
OPT./CP, MOC 3011
E-620-172
5
1
R2
1000,5%,1f4W
E-105-301
6
1
Ql
sea,
S2800A
E-585-65
,.
7
1
Bolt, #6-323;8" LG.
lSPR-00632-1106
8
1
Nut, #6-32
N-00632-2112
9
1
Heat Sink, 6030BTT
E-682-8
...
10
AR
Thermal Grease
M-1834
REF
Schematic
W-1252-b
...•
32
