SQUAWK & TALK MODULE
AS 2518-61A
COMPONENTS PARTS LIST
REFERENCE
BALLY
ITEM
QTY.
DESIGNATION
DESCRIPTION
PAAT#
26
1 R37
Resistor,
V4W,
5"!o,30K
E-l05-245
27
5 R12,36,57,58,81
Resistor, Y4W,5%, 1K
E-l05-230
28
1 R51
Resistor,
V4W,
5%, 750K
E-l05-344
29
1 R52
Resistor, Y4W,5%, 9.1K
E-105-228
30
2 R9,16
Resistor, Y4W,5%, 130K
E-l05-203
31
1 Rll
Resistor, %W, 5%, 150K
E-l05-248
32
1 R15
Resistor, %W, 5%, 220K
E-l05-161
33
1 R14
Resistor, Y4w, 5%, 1.8K
E-l05-346
34
4 RH, 18, 39, 40
Resistor, %W, 5%, 9i0K
E-l05-347
35
1 Ri
Resistor, Y4w, 5%, 27K
E-l05-243
36
1 R68
Resistor, V4W,5%, 510
n
E-105-311
hr.
37
1 R34
Resistor, 1f4W,5%, 2.2
n
E-l05-211
38
3 R31, 88, 89
Resistor, %W, 5%, 220
n
E-l05-303
39
1 R79
Resistor, Y4W,5%, 7.5K
E-l05-345
40
1 R35
Resistor, 1f4W,5%,1
n
E-l05-196
i.,
41
1 R83
Resistor, V4W,5%, 11K
E-l05-360
42
1 R7
Resistor, %W, 5%. 8.2K
E-l05-223
43
14 C2, 5-8, 10, 11,17,18,44,47-50
Capacitor, Ceramic, .01j..tF,25V
E-586-85
44
2 C23,35
Capacitor, Ceramic, ,47j..tF,16V
E-586-130
45
4 R84-87
Resistor, 1f4W,5%, 2.2K
E-l05-287
46
1 R6
Resistor,
V4W,
4700
E-l05-342
47
7 C19,24,25, 28,31,34,42
Capacitor, Electrolytic, 1fLF,25V
E-586-90
48
10 C12,13,26,30,33,39,4O,41,
45,46
Capacitor, Ceramic, .1j..tF,25V
E-586-89
49
2 C9,20
Capacitor, Ceramic, 470pF, 50V
E-586-83
50
1 C32
Capacitor, Ceramic, 68pF
E-586-120
51
1 C21
Capacitor, Ceramic, 100pF
E-586-68
52
1 C15
Capacitor, Electrolytic, 10j..tF,16V E-586-135
'"
53
2 C16,22
Capacitor, Tantalum, 4.7j..tF,25V
E-586-73
54
1 C27
Capacitor, Electrolytic, l000j..tF, l6V E-586-136
55
1 C29
Capacitor, Electrolytic, 470j..tF,6V E-586-124
56
2 C3,4
Capacitor, Ceramic, 27pF
E-586-121
..
57
1 C14
Capacitor, Electrolytic, 4700j..tF, 25V E-586-123
58
2 C37,38
Capacitor, Electrolytic, 330j..tF,50V E-586-147
59
1 C51
Capacitor, Monolythic, 10pF
E-586-150
60
1 Jl
18 Pin Wafer Connector (156)
E-736-18
••
61
1 J2
6 Pin Wafer Connector (156)
E-736-6
62
1 Used with VRl
Heatsink, 60538
E-682-11
63
1 Used with U18
Heatsink, 60308
E-682-8
64
12
Test Points
P-5399
•..
65
1 Sw. 1
P.C.B. Switch
E-658-1
66
3 CR7, 8,10
Diode (IN4004)
E-587-15
67
5 CRl , 5, 6, 9, 11
Diode (IN4148)
E-587-14
68
1 Vl
Crystal,3.579
E-744-5
•...
69
1 LEDl
LED
E-679
70
3 Ql-2,5
Transistor, 2N3904
E-585-31
71
1 Used with U10
Socket I.C. 16 Pin
E-712-16
72
3 CR2-4
Diode, VR332
E-587-22
73
1 Ul
6808 or 6802 (SEE NOTE 1)
Microprocessor
E-620-125 or 128
74
3 Used with Ul, 7,11
Socket, I.C. 40 Pin
E-712-1
75
3 Used with U8, 9,12
Socket, I.C. 28 Pin
E-712-2B
76
3 Used with U18, VRl
Screw
LSPR-00632-1106
77
3 Used with U18, VRl
Nut
N-00632-21l2
78
2 J3
Header, 20 Pin
E-766-20
80
2 C36,43
Capacitor, 2j..tF,16V
E-586-63
••
81
2 R69,70
Pot lK
E-599-16
82
1 C1
Capacitor, Electrolytic, 47fLF
E-586-148
83
2 R28,54
Resistor, 82K
E-l05-341
84
AR Used with U18, VRl
Thermal Compound
M-1834
.•
85
2 Q3,4
Transistor, 2N4403
E-585-23
86
2 R82,48
Resistor, %W, 5%, 2.4K
E-l05-312
JUMPERS-SEE NOTES
