A4:
MPU MODULE
COM PON ENT PARTS LIST
-
REFERENCE
BALLY
ITEM
DESIGNATION
PART
#
DESCRIPTION
---~~~
1
A4 (see note 1)
AS-2962-27
MPU Module Complete.
;:;,;.,
.
2
A4 (see note 2)
AS·2518·35
MPU Module less Program
-
Memory, U1·6 incl.
.•.
3·32
See Schematic
Resistors, See schematic for value
'"
33
C14,C15
E-00586-0067
Capacitor, 470 PFD, 1kv
,
34
C18
E·00586·0088
Capacitor, .05 MFD, 16V
35
C16
E·00586-0081
Capacitor,.1 MFD, 100V
-,
36
C4,C5
E·00586-0073
Capacitor, 4.5 MFD, 25V
37
C3, C6·C13, CIl, C81
E·00586·0085
Capacitor, .01 MFD, 25V
38
C79, C41-C67
E·00586-0083
Capacitor, 470 PFD, 50V
-.
39
C19-C31, C78, C33-C40
E·00586-0082
Capacitor, 390 PFD, 50V
40
C 1, C2, C68·C77
E·00586·0084
Capacitor, 820 PFD, 50V
41
C32
E-00586-0077
Capacitor, 3000 PF, 1kv
~
43
05
E-00585-0023
Tran si stor PN P (M PS·3702)
44
01, Q2
E·00585·0031
Transistor (2N3904)
47
CR44
E·00587 ·0006
Diode (IN4004)
-
48
CR1-CR7, CR11-CR43,
E-00587-0014
Diode (lN4148)
,
.
CR45-CR49
49
CR8
E-00679
LED (Green)
..•...
50
VR1
E-00598-0008
Diode Zener (8.2V, IN9598)
52
L1, L2
E·00604·0003
Inductor, 22 Micro
Hy.
53
U12
E-00620·0004
Timer (555)
54
U19
E·00620·0005
Quad 21nput (4011)
-
55
U9
E-00620-0028
MPU I.C. (6800)
56
U10, U11
E·00620·0029
PIA I.C. (6820)
57
U7
E·00620-0030
RAM I.C. (6810)
\
59
U20
E·00620-0032
H
EX Buffer I.C. (14502B)
-
60
U14, U18
E-00620-0033
H
EX Inverter (4049B)
61
U15
E-00620-0034
Quad Memory Drive (MC3459L)
62
U16
E·00620·0035
Dual Monostable (9602)
\
-
64
U17
E·00620·0041
Quad 21nputs (74LOON)
-.
65
U8
E-006 20-0042
RAM (C MOS, P5101 L·3)
68
BT1, BT2, BT3
E-006 28-0003
Battery
70
S33
E·00658·0001
Push Button Switch
""\,
71
S1-S8, S9-S16, S17-S24,
E-00677
DIP Switch
825-832
73
E~00712
24 Pin Socket
74
E-00712-0001
40 Pin Socket
-.
75
E-00712-0003
22 Pin Socket
77
J2
E-00715
15 Pin Wafer Connector
78
J1
E-00715-0004
28 Pin Wafer Connector
79
J3, J5
E-00715·0017
16 Pin Wafer Connector
80
J4
E·00715·0018
19 Pin Wafer Connector
81
J5
E-00715-0024
17 Pin Wafer Connector
NOTE
1:
When ordering, fill in dash number. For example. AS-2962-0: LOST WORLD. AS-2962-2: SIX MILLION DOLLAR
MAN. AS-2962-3: PLAYBOY, AS-2962-4: VOLTAN, AS-2962-S: SUPERSONIC, AS-2962-6: STAR TREK.
AS-2962-7: KISS. AS-2962-8: PARAGON. AS-2962-9: GROUND SHAKER. AS-2962-1O: HARLEM GLOBE-
TERS, AS-2962-12: DOLLY PARTON, AS-2962-13: SILVERBALL MANIA, AS-2962-18: MYSTIC, AS-2962·20
HOTDOGGIN, AS-2962-22: SKATEBALL, AS-2963-23: FRONTIER, AS-2962-21: XENON, AS-2962-24:
FLASH GORDON, AS-2962-26: EIGHT BALL DELUXE. AS-2962-2S: FIREBALL II, AS-2962-27. EMBRYON.
NOTE
2:
Order replacement memory chips U1-U6, specifying game. socket and part number stamped on chip.
