PLAYFIELD PARTS
See Figure II
XI. PARTS LIST
#1222 EMBRYON
...•
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
E-122-142
Bulbs, #555
E-12S-73
Fuse, 1 Amp. 3 AG Slow Blow (Playfield Solenoid Protection)
E-133-44
..•
ASSEMBLY COILS
Coin Lockout
FO-36-7000
Flipper (3)
AQ-25-500/
34-4500
Right Outlane Flipper
AO-27 -1300
Knocker
AR-26-1200
Outhole Kicker
AO-27 -1300
Thumper Bumper (4)
AN-26-1200
Sling-Shot (2)
AO~26-1200
Drop Target Reset (2)
NO-26-1 900
Single Drop Target Reset
AO-27-1300
Saucer (1)
AO-27-1300
-
...•.
MODULES
Lamp Driver AS
AS-2518-23
Display Driver A1 (5 used)
AS-2S18-21
-
Solenoid Driver/Voltage Regulator A3
AS-2518-22
MPU A4
AS-2962-27
Transformer & Rectifier A2
'.'
AS-2877-6
Rectifier Board (Part of A2)
AS-2S18-S4
Squawk
&
Talk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. AS-31 07-4
Auxiliary Lamp Driver A9
AS-2S18-S2
Aux. Driver (SCR Lamp Flasher)
AS-2S18-67
•••
REPAIRS PROCEDURES/AIDS
Module & Component Replacement
F.O.560-1
AID (Assistance in Diagnostics)
Kit. used with F.O.S60-1
KIT #48S-1
MODULE COMPONENTS
SEE MODULE PARTS LIST
MODULE COMPONENT STARTER KITS
(Each kit contains an assortment ofthe most needed electronic parts for use in Module repair.)
KIT #558-For
Rectifier Board (Part of A2)
KIT #503-For
MPU Board A4 (Less Memory U1-U6)
KIT #492-For
Solenoid Driver/Voltage Regulator A3
KIT #493-For
Display Driver A1
KIT #494-For
Lamp Driver AS
20
