SOLENOID IDENTIFICATION
SINGLE DROP TARGET RESET
LEFT SIDE 3 BANK RESET
TOP 3 BANK RESET
SAUCER
COIN LOCKOUT DOOR
KI RELAY (FLIPPER ENABLE)
RIGHT OUTLANE FLIPPER
GAME #1222 EMBRYON (FIGURE V)
SOLENOID IDENTIFICATION TABLE
Self
Test
#
01
02
03
04
05
06
07
08
SOLENOID IDENTIFICATION
LEFT SLINGSHOT
RIGHT SLINGSHOT
LEFT TOP THUMPER BUMPER
LEFT BOTTOM THUMPER BUMPER
RIGHT TOP THUMPER BUMPER
RIGHT BOTTOM THUMPER BUMPER
KNOCKER
OUTHOLE KICKER
Self
Test
#
09
10
11
12
13
14
15
DESCRIPTION
3 TOP DROP TARGETS (CENTER)
3 TOP DROP TARGETS (LOWER)
#1
ROLLOVER
#2 ROLLOVER
3 LEFT DROP TARGETS (UPPER)
3 LEFT DROP TARGETS (CENTER)
3 LEFT DROP TARGETS (LOWER)
LEFT SIDE CAPTIVE BALL TARGET
CENTER RIGHT UPPER TARGET
CENTER RIGHT LOWER TARGET
CENTER LEFT LOWER TARGET
CENTER LEFT UPPER TARGET
RIGHT CENTER INSIDE TARGET
LEFT CENTER INSIDE TARGET
RIGHT SLINGSHOT
LEFT SLINGSHOT
RIGHT BOTTOM THUMPER BUMPER
RIGHT TOP THUMPER BUMPER
LEFT BOTTOM THUMPER BUMPER
LEFT TOP THUMPER BUMPER
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
Switch
Self
Test
#
DESCRIPTION
01 10 POINT REBOUND (4)
02 ROLLOVER BUTTON (3)
03 RIGHT FLIPPER BUTTON
04 SAUCER
05 #1 LEFT AND RIGHT OF OUT HOLE
06 CREDIT BUTTON
07 TILT (3)
08 OUTHOLE
09 COIN III (RIGHT)
10 COIN I (LEFT)
11 COIN" (MIDDLE)
12 "A" ROLLOVER
13 "8" ROLLOVER
14 RIGHT OUTLANE
15 LEFT OUTLANE
16 SLAM (2)
17 SINGLE DROP TARGET*
18 SPINNER
19 TOP CENTER ROLLOVER
20 3 TOP DROP TARGETS (UPPER)
Switch
Self
Test
#
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
*WITH TARGET DOWN PULSE BACK TARGET.
#17-
STOPS FLASHING AND "0" STARTS FLASHING.
NOTE: SLINGSHOT
&
THUMPER BUMPER COILS
'-WILL ENERGIZE WHEN SWITCH IS MADE.
