EMBRYON
•
•
;
I
I
!
I
I
'
I
PANEL TOP PARTS
P-5871-85
P-6359-50
A-1475-15
C-694-2
C-693-2
(3)
ASE-428-44
ASE-2250-11
ASE-2250-86
ASE-2250-24
ASE-22S0-77
ASE-22S0-89
A-2898-43
A-2898-42
A-4009-3 (4)
C-1018-2 (4)
ASE-2806-10
ASE-28-6-9
A-3032-70
A-3032-71
A-3032-72
A-3032-73
P-6244-119
ASE-2911-21 (4)
ASE-2911-3 (3)
ASE-2795-86
ASE-2795-87
ASE-2993-13
M-121-113 (2)
M-121-111
M-121-112
M-121-110
M-121-109
M-121-9o (4)
M-121-53 (2)
M-121-24
A-3994
(3)
A-2836-2 (4)
A-2890-157
M-1330-186
M-121-18
ASE-982-1311
A-4013-1
1. Bottom Arch
2. Shooter Gauge
3. Ball Gate
4. Plastic Guide
5. Plastic Guide
6. Eject Hole
7. Gate
&
Wire Assy.
8. Spinner Assy.
9. Gate
&
Wire Assy.
10. Gate & Wire Assy.
11. Gate
&
Wire Assy.
12. Ball Guide Assy.
. 13. Ball Guide Assy.
14. Bumper Cap
15. Bumper Collar
16. Wire Actuator
17. Wire Actuator
18. Ball Guide Assy.
19. Ball Guide Assy.
20. Ball Guide Assy.
21. Ball Guide Assy.
22. Ball Guide
23. Target Switch
24. Target Switch
25. Drop Target Assy.
26. Drop Target Assy.
27. Drop Target Assy.
28. Guide Wire
29. Guide Wire
30. Guide Wire
31. Guide Wire
32. Guide Wire
33. Guide Wire
34. Guide Wire
35. Guide Wire
36. Molded Flipper
• 37. Mini Post
• 38. Screened Plastics (Set)
39. Screened Plastics (Set)
40. Guide Wire
41. Target Switch
42. Transparent Flipper
i
a"
\\
I ,'\
\i
I
I
1\
II
I
\
I
~
IW
\"'i>~5
0
a
a
a
o
22
1
RUBBER PARTS
A.
R-521
3/4"
(4)
B.
R-S21-1
1"
(4)
C.
R-521-2
11fz"
(2)
D.
R-521-3
2"
(5)
E.
R-521-4
2112"
F.
R-521-S
3"
G.
R-243
5/16"
(13)
H.
R-533-3
FLIPPER (3)
I.
R-521-9
5"
9
