Thumper Bumper Assembly Parts List
C-12842
ITEM DESCRIPTION
PARTNUMBER
1 Coil
&
Tubing Assy
AE-23-800
Diode: 1N4004GP. 1.0A 5070-06258-00
Tubing
03-7066
2 Core Plug Assy
&
Brkt Assy B-12749
3 Base: Thumper Bumper
03-8324-5
4 SwitchAssy
01-9166
5 Make Switch Plate
01-9321
6 Bracket
01-9319
7 Mounting Bracket
01-9117
8 Plunger
02-3406-1
9 Spring Washer:
0017-00104-0073
.515i.d ...8750.d ...OI3th.
10 Bracket Plate
01-9116
11 Plate. Bakelite
01-9320
12 Compression Spring
10-411
13 Lamp. =#555:Wedge Base 24-8768
14 Socket: Lamp
24-8813
15 Not Used
16 Body:WhUe
03-8325-5
17 Flange
&
Stud Assy
A-4754
18 Wafer: White
03-8517-5
19 Compression Spring
10-326
20 Nut: =#8-32Locking
0017-00103-0041
21 Nut: =#6-32Locking
0017-00103-0052
_._._._._0_'_'_'_0_'_' ___ .___ ._._0-
Thumper Cap
03-8291-9
Thumper Bumpers
2-25
