Ball Eject (Shooter Lane Feeder) Assembly
C-9638
ITEM DESCRIPTION PARTNUMBER
1 Hair Pin Clip
12-6227
2 Ball Eject Cam
Assy
A-8247
3 Spring
10-362
4 Spring Plate
Assy
A-6949-L
2
5 Plunger Assy
A-8050-1
a) Coil Plunger
02-3407-2
b) Poll Pin
20-8716-5
cl
Armature IJnk
03-8085
6 Hair Pin Clip
12-6227
7 Washer, 1/20.d. x 4700-00030-00
17/64i.d. x 15 gao
8 Washer, 1/20.d. x 4700-00103-00
17/64i.d. x 28 gao
9 Mounting Brkt Assy A-8268
-------------------------------------------------------
Associated Coil
&
B-9362-R-l
Bracket Assembly
Outhole Kicker Assembly
8-8039-2
Ball Eject
2-20 Outhole Kicker
ITEM DESCRIPTION PARTNUMBER
1 Mounting Plate ASsy A-6378
2 Coil Plunger Assy A-8335
al
Coil Plunger
02-2364
bl
Roll Pin, 1/8x7/16 20-8716-5
cl
Ball Return Unk
01-4251
3 Coil Tubing
03-7066
4 Kicker Lever Assy A-6889
5 Coil Stop Assy
A-8038
6 Coil ASsy
AE-23-800
7 Striker Ring
03-7176-1
8 Reset Spring
10-010-4
9 E-Ring, 1/4" Shaft
20-8712-25
10 Mach. Screw,
4006-01003-03
6-32x3/16 P-PHS
