NEVER
transport a pinball game with hinged backbox erect. Always lower the
backbox forward onto the playfield cabinet on a layer of protective material to
prevent marring or damage and possible personal injury.
5. Extend each leg leveller slightly below the leg bottom. so that all four foot pads
are extended about the same distance.
Remove the cabinet from its support and
place it on the floor.
6. Adjust the leg levellers for proper playfteld level (side-to-side) and playfteld pitch
angle (incline) of approximately 7 degrees. (Again. it is recommended that these
measurements be made ON the playfleld, not the cabinet nor the playfteld cover
glass.) Tighten the nut on each leg leveller shaft to maintain this setting. as shown
in Figure 3.
U 'tD
Ii:!!
Playing pitch angle adjustments can affect the operation of the plumb bob
tilt. inside the cabinet. The plumb bob weight is among the parts in the
cash box: the operator should install the weight and adjust this tilt
mechanism for proper operation. after completion of the desired playfleld
pitch angle setting.
7. Move the game into the desired location: recheck the level and pitch angle of the
playfield.
8. Verify that the required number of balls are inside the game.
9. Clean and re-install the playfteld cover glass. Prepare the game for player
operation.
