6803 CONTROL BOARD
A084-91786-COOO
M051-0OC53-C003 (Page 3 of 4)
DESIGNATION LIST
DESIGNATION
DESCRIPTION
R165 - R168
R169 - Rl72
R173 - R187
R188 - R190
R191 - R193
R194 - R196
R197 - R226
R227,R228
R229
R230
R231 - R234
R235
R236
01
02
03
04,05
06
07,08
09 - 018
D19 - 038
039
01
02
03
04
05
06
07 - 022
023 - 033
034 - 036
037
038 - 040
041 - 050
051 - 053
054 - 064
065 - 068
069,070
U1
U4
U5
U6
U7,U8
U9
Ul0
U 11
U12
U13
U14
120 OHM 1/4W 5%
330 OHM 1/4W 5%
2K 1/4W 5%
1.2K 1/4W 5%
120 OHM 1/4W 5%
330 OHM 1/4W 5%
2K 1/4W 5%
1.2K 1/4W 5%
56K 1/4W 5%
1.2K
1/4W 5%
330 OHM 1/4W 5%
3.3K 1/4W 5%
1.2K
1/4W 5%
1N9588
lN4606
1N4148
lN4606
lN4148
lN4606
lN4148
lN4004
1N4148
2N5305
2N3904
2N4403
2N3904
2N4403
2N3904
SE9302
2N5060
MCR 106-1
2N5060
SE9302
2N5060
MCR 106-1
2N5060
MCR 106-1
2N5060
6803
6116 RAM
74HCT245
74LS373
6821
74LS10
74LS04
4011
4584
4502
74LS 154
