Item Part No.
1 02-4003
2 C-11626-L-3
a) 20-9250-6
3 B-12513
4 12-6835
5 12-6466-10
6 B-9463
7 R-12487
8 C-11626-L-6
a) 20-9250-6
9 B-11696-1
10 A-12525
11 A-12523
12 A-12557
a) 12-6731-1
13 B-12514
14 B-9361-R
a) 03-7351-1
15 01-9051
16 B-9414
17 C-11223-1
18 B-12515
19 0-12364
20 A-12517
21 0-12364
22 B-12526
23 B-12586
a) 12-6780
24 A-12522
25 A-12589
a) 12-6565
26 A-12500
a) 12-6733
b) 12-6785
27 C-12429
28 0-12563
29 12-6813
30 0-11335-2
31 0-12562
32 C-12564
33 12-6814
34 B-12728
35 A-12351
36 C-12561
37 0-12489
38 B-12527
39 B-12583-6
40 A-12524
41 A-12558
a) 12-6796
42 C-12584
43 B-12516
44 B-11696-5
46 B-12516
47 0-12642
Playfield Parts
Description
Post
Lwr Left Flipper Assy
Lg Flipper Paddle & Shaft
Left Flipper Retum Frame
Bottom Arch Fence
Wireform,
2-1/2"
Kicker Arm ("Sling") Assy
Center Ramp Assembly
Upper Left Flipper Assy
Lg Flipper Paddle & Shaft
Standup Target, Blue
Ball Guide Assembly
Ball Guide Assembly
Ball Gate Assembly
Gate Wire
Ball Guide Assembly
Eject Hole
Tr Red Plastic Ball Seat
Ball Oeflector
Jet Bumper Assy (3)
3-Bank Orop Target
Ball Guide Assembly
Spiral Ramp Exit Chute
Ball Guide Assembly
Spiral Ramp Base Portion
Ball Guide Assembly
Spinner Assy
Switch Wire
Ball Guide Assembly
Ball Gate Assembly
Gate Wire
Switch Gate Assembly
Gate Wire
Switch Wire
Zone Opener Assembly
Ball Guide Assembly
Upr Right Wire Ramp
Top Ball Popper
Ball Guide Assembly
Ball Guide Assembly
Mid Right Wire Ramp
Building Assembly
Orop Hole OeflecVBracket
Ball Guide Assembly
Right Ramp Assembly
Ball Guide Assembly
Standup Target, Yellow
Ball Guide Assembly
Ball Gate Assembly
Gate Wire
Bridge (Signs) Assembly
Ball Guide Assembly
Standup Target, White
Ball Guide Assembly
Bottom Ball Popper
Item Part No.
Description
48 12-6812
Lwr Right Wire Ramp
49 12-6466-6 Wireform,
1-1/2"
50 B-9463
Kicker Arm ("Sling") Assy
51 C-12579
Ball Guide Assembly
52 C-9638
Ball Shooter Lane Feeder
53 C-11626-R-3 Lwr Right Flipper Assembly
54 B-8039-2
Outhole Kicker Assy
55 A-12506
Switch Gate Assembly
56 A-12521
Ball Guide Assembly
57 A-12560
Ball Guide Assembly
58 B-12512
Rt Flipper Return Frame
(Playfield Parts beneath Bottom Arch)
B-8623
Upr Trough Baffle Assy
01-5575
Bottom Arch Mtg Bracket
C-8235
Lwr Trough Baffle Assy
12-6542
Baffle Wire form
01-3569-1 Ball Trough
EARTH SHAKER 70
