High Current Driver
pIn
C-12493
Item Part No.
Ckt
Designator
Description
1 5768-12372-00
High Current Driver P.C.B.
2 5191-12179-00
Q1
Transistor, TIP36C
3 5010-09160-00
R1
Resistor, 220Q, 1/4w, 5%
4 5070-09054-00
01
Diode, 1N4004, 1.0A
5 5705-09172-00
Heatsink, 60728
6 5791-10862·06
J1
Connector, 6-pin Hdr Sq Pin .156
7 5791-10862-05
J2
Connector, 5-pin Hdr Sq Pin .156
8 4406-01128-00
Nut, 6-32 KEPS
9 4006-01017-08
Mach. Screw, 6-32 x
1/2
High Current Driver Circuit Schematic
EARTHSHAKER 61
