Coin Door Assembly
2-Chute Door,
pIn
09-17002-x
3-Chute Door,
pIn
09-17003-x
("x" Is the country designator)
Item Part No.
Description
Quantity
1 27-1038
Button Cover
2or3
2 27-1041-1·41
Price Panel
2 or 3
3 27-1026-1-13
Coin Entry Plate
20r3
4 27-1016
Lock Assembly
1
5 27-1061
Coin Return Bezel
1
6 27-1062
Coin Return Flap
1
7 27-1021
Button Housing - 2-slot
1
27-1022
Button Housing - 3-slot
1
8 27-1111
Interlock Switch
1
9 27-1006
Coin Door - 2-slot
1
27-1007
Coin Door - 3-slot
1
10 27-1005
Coin Door Frame
1
11 27-1003
MIC
Screw, 6-32 x
3/16
4
12 27-1008
Diagnostic Switch
1
13 27-1101
MIC
Screw, 4-40 x
1/4
2
14 27-1102
Bracket, Diagnostic Switch
1
15 27-1037
Button
2or3
16 27-1078
MIC
Screw, 6-32 x
3/8
20r3
17 27-1039
Conical Spring
2 or 3
18 27-1079
Self-tapping Screw, #6 x
1/4
2
19 27-1077
Coinbox Cover
1
20 27-1066
Slam Switch
1
21 27-1067
MIC
Screw 4-40 x
1/2
2
22 27-1017
Nut (key)
1
23 27-1012
Locking Cam
1
24 27-1011
Locking Arm
2
25 27-1020
Washer
1
26 27-1018
Star Washer
1
27 27-1019
MIC
Screw
1
28 27-1089
R-Ring
1
29 27-1083
Retainer
1
30 27-1081
Coin Inlet Chute
2 or 3
31 27-1088
Wire Clamp
2 or 3
32 27-1025
Key Hook
2 or 3
33 27-1086
Washer, #6
20r3
34 27-1078
MIC
Screw, 6-32 x
3/8
2 or 3
27-1078
MIC
Screw, 6-32 x
7/8
20r3
35 27-1079
Self-tapping Screw, #6 x
1/4
2 or 3
36 27-1084
Lamp Socket
2 or 3
27-1085
Lamp
2
Or
3
37 27-1096
Self-tapping Screw, #5 x
3/8
2 or 3
38 27-1087
MIC
Screw, 6-32 x
5/8
2 or 3
39 27-1082
Lever Arm
20r3
40 27-1097
Switch Cover
20r3
41 27-1091
Coin Accept Chute
2or3
42 27-1075
Wire Form
20r3
27-1093
Wire Form
20r3
43 27-1094
MIC
Screw, 6-40 x
7/8
2
44
27-1087
MIC
Screw, 6-32 x 5/8
2
45 27-1086
Washer, #6
2
46 27-1095
Nut, 4-40
2
47 27-1076
Coin Return Box
1
48 27-1078
MIC
Screw, 6-32 x 3/8
2
49 27-1092
Microswitch
2 or3
EARTHSHAKER 54
