Ball Shooter Lane Feeder
pIn
C-9638
& Associated Parts
Item Part No.
1 12-6227
2 A-8247
3 rO-362
4 A-6949-L
5 A-8050-1
a) 02-3407-2
b) 20-8716-5
c) 03-8085
6 4700-00030-00
7 4700-00103-00
8 A-8268
Description
Clip, Hairpin
Eject Cam Assembly
Ejector Spring (Plain)
Spring Plate Assembly
Coil Plunger Assembly
Coil Plunger
Roll Pin
Armature Link
Flat Washer, 17/64 x 1/2 x 15 ga
Flat Washer, 17/64 x 1/2 x 28 gao
Mounting Bracket Assembly
Outhole Kicker Assembly
pIn 8-8039-2
Item Part No.
1 A-6378
2 A-8335
a) 02-2364
b) 20-8716-5
c) 01-4251
3 03-7066
4 A-6889
5 A-8038
6 AE-23-800
7 03-7176-1
8 10-101-4
9 20-8712-25
10 4006-01003-03
Description
Mounting Plate Assembly
Coil Plunger Assembly
Coil Plunger
Roll Pin, 1/8 x 7/16
Ball Return Link
Coil Tubing
Kicker Lever Assembly
Coil Stop Assembly
Coil Assembly
Striker Ring
Spring-Reset
"E" Ring, 1/4" Shaft
Mach. Screw, 6-32 x 3/16
BALL SHOOTER LANE FEEDER
Associated Parts
B-9362-L-1
B-7572-1
01-8-508-S
4006-01017-06
4406-01119-00
AE-23-800
03-7066
Coil & Bracket Assy
Bracket & Stop Assy
Coil Retaining Bracket
Mach. Screw, 6-32 x 3/8
Nut, 6-32 ESN
Coil Assembly
Coil Tubing
OUTHOLE KICKER ASSEMBLY
EARTHSHAKER 51
