• EARTHSHAKER
(System
11B)
ROM Summary
• Pinball Game Assembly Instructions
• Game Play
• Game Status Displays
• Game Adjustment Procedure
• Game Pricing
• Test/Diagnostic Procedures
EARTHSHAKER
(System
11B)
ROM Summary
IC
DESCRIPTION TYPE IDENTIFIER BOARD PART NUMBER
Game ROM 1
32Kx8 ROM 27256
U27
CPU A-5343-568-2
Game ROM 2
32Kx8 ROM 27256
U26
CPU ...A-5343-568-1
. Sound ROM 1 ' 32Kx8 ROM 27256
U21
CPU A-5343-568-4
Sound ROM 2
32Kx8ROM 27256
U22
CPU A-5343-568-3
MusiC/Speech ROM 1 32K x 8 ROM 27256
U4
Audio A-5343-568-5
Music/Speech ROM 2 32K x 8 ROM 27256
U19
Audio A-5343-568-6
J:lI01fllCIE
To order a replacement ROM from your authorized WILLIAMS ELECTRONICS GAMES
distributor. specify: (1) part number
(if
available); (2) ROM label color; (3) ROM level
(number) on the label; (4) which game the ROM is usedin.
EARTHSHAKER 1
I
I
I
-. . . . ,-
