6803 PINBAllA084-91
MOSl-OO
DESIGNATIO" LIST
DESIGNATION DESCRIPTION
Cl 1l,OOOuf 20V ELEC.
P/O C1 TY-WRAP
PIO C1 SOLOER LUG
PIn C1 WIRE ?OAWG
C? 1110uf 350V fLEC.
PIn C2 TV-WRAP
C3 2uf 25V ELEC.
C4, C5 .1uf 25V CER.
C6, C7 .Oluf SOOV CER.
R1 600 OH"1 lOW
R2 lOOK 1W 5%
R3 2.2 OHM l/4W 5%
R4 100 OHM l/2W 5%
R5 221< 1/2W 5%
R6 lOOK 1/4~1 5%
R7 390 OHM 1/4W 5%
R8 1. 2K 1/4W 5%
R9 82K 1/2W 5%
RIO 8.2K 1/4W 5%
VRI o - 25K 1/4W POT.
01 - 04 MR751
05 - 09 IN4004
010 HI5275A ZENER
SRI KBPC-35-02-W
PIn BR1 RRIDGE SPACER
01 2N3584
PIO 01 SHIELD
PIn 01 HEX SPACER
PIO 01 6-32 X 5 SCREW
PIn 01 6-32 X 12 SCREW
PIO 01 LOCKWASHER EXT.
PIO 01 LOCKWASHER INT.
PIn 01 FLAT WASHER
P/O 01 6-32 HEX NUT
P/O 01 LABEL - CAUTION HIGH VOLT.
PIO 01 HEATSINK ?
P/O 01 I"'SULATOR TO-66
02, Q3 2N3440
PIO Q2, 03 INSULATOR TO-5
PIO 03 HEATSINK 3
U1 78HOSC REG.
P/O U1 6-32 X 12 SCREW
P/O U1 6-32 HEX NUT
P/O U1 LnCKWASHER F.:XT.
P/O U1 FLAT WASHER
P/O Ul HEATSINK 1
P/O Ul INSULATOR TO-3
VAl V.~RISTOR
