FIGURE
n c
XII
OH08 DUNGEONS
&
DRAGONS
PANEL TOP PARTS
1. FLIPPER ASSEMBLY SINGLE
AC70-00022-0100
SWITCH RIGHT
2. FLIPPER ASSEMBLY SINGLE
AC70-00022-0200
SWITCH LEFT
3. FLIPPER ASSEMBLY DOUBLE
AC70-00023-0100
SWITCH RIGHT
4. THUMPER BUMPER ASSEMBLY
A967 -00053-0100
5. SLINGSHOT KICKER ASSEMBLY
A967 -00059-0000
LEFT
&
RIGHT
6. BALL SAVER ASSEMBLY LEFT
AE94-00040-0000
7. BALL SAVER ASSEMBLY RIGHT
AE94-00041-0000
8. MULTI-BALL ~ICKER ASSEMBLY
AH01-00027-0000
9. BACKBOARD ASSEMBLY
AH06-00009-0000
10. TOP PLATFORM ASSEMBLY
AH06-00024-0000
11. DROP TARGET ASSEMBLY
AH06-00042-0000
3 IN-LINE
12. TELEPORT DROP TARGET ASSEMBLY A365-00374-0100
13. KNOCKER ASSEMBLY 2-LUG
AH06-00045-0000
LEFT
14. TOP MOUNTED KICKER ASSEMBLY A360-00234-0000
15. KNOCKER ASSEMBLY 2-LUG
A360-00235-0000
RIGHT
16. TARGET, SWITCH, BRACKET, DIODE,
A365-R030S-F113
& CAP: YELLOW; LUG RIGHT
17. TARGET, SWITCH, BRACKET, DIODE,
A365-R0307-F111
& CAP: RED; LUG RIGHT
18. TARGET, SWITCH, BRACKET, DIODE,
A365-R0307-F112
& CAP: BLUE; LUG RIGHT
19. SHAFT W/ARM & STUD ASSEMBLY:
A365-00321-0100
RIGHT
20. SHAFT WiARM & STUD ASSEMBLY:
A365-00321-0200
LEFT
21. OPTlCAL MULTI-BALL
A365-0034 7-0100
TROUGH ASSEMBLY
22. TELEPORT DROP TARGET ASSEMBLY A365-00374-0100
23. GATE, BRACKET & WIRE FORM
AA40-00034-0000
ASSEMBLY
24. GATE, BRACKET
&
WIRE FORM
A360-00214-0000
ASSEMBLY
25. GATE, BRACKET & WIRE FORM
AH06-00025-0000
ASSEMBLY
26. WIRE-TO-MOUNTING BRACKET
AH06-00021-0000
ASSEMBLY
27. BRACKET WIWIRE FORM ASSEMBLY:
A331-00042-0000
ROLLOVER LEFT
28. BRACKET WIWIRE FORM
A360-00217 -0000
ASSEMBLY: ROLLOVER LEFT
29. SWITCH ASSEMBLY: ROLLOVER
A020-00095-0111
W/DIODE & CAP
30. SWITCH ASSEMBLY: GATE
A020-00094-0111
W/DIODE & CAP
31. SWITCH W/BRACKET & PLATE
A360-00230-0000
ASSEMBLY: SLINGSHOT
32. SWITCH/BRACKET & DIODE
A360-00239-0000
ASSEMBLY: REBOUND
33. SWITCH W/DIODE & CAP ASSEMBLY A360-00S03-0002
34. SWITCH W/DIODE & PLATEASSEMBLY A365-OOO34-0000
35. SWITCH W/DIODE & PLATE ASSEMBLY A3S5-00035-OOOO
3S. LIGHT DOME: PLASTIC, BLUE
0017-00042-0742
37. LIGHT DOME: PLASTIC, CLEAR
0017-00042-0745
38. WIRE FORM: LEFT BALL CAPTURE OHOS-00905-0000
39. WIRE FORM RAMP UNIT: RIGHT
OH06-00910-00XF
40. WIRE FORM RAMP UNIT: LEFT
OH06-00911-00XF
41. WIRE FORM: INSIDE DRAIN RIGHT
OHOS-00913-0100
42. WIRE FORM: INSIDE DRAIN LEFT
OH06-00913-0200
43. WIRE FORM: BALL GUIDE
0360-00175-5300
44. WIRE FORM: BALL GUIDE
0365-00151-2000
45. PLATE: LEFT RAMP ENTRANCE
OHOS-00134-0000
46. CAP: THUMPER BUMPER, AMBER
0017-00042-0520
47. COLLAR: THUMPER BUMPER, RED 0017 -00042-0566
48. SHOOTER GAUGE
OH06-00100-00XF
49. BOTTOM ARCH
OH06-00921-0000
50. BOTTOM ARCH EXTENSION
0370-00918-1000
51. LEFT RAMP ENTRANCE ASSEMBLY AH06-00048-0000
52. SCOOP: LEFT BALL CAPTURE
OHOS-00104-0000
53. RIGHT BALL CATCH ASSEMBLY
AH06-00029-0000
1-13
