FIGURE. a
1-10
VII
OHOe DUNGEONS" DRAGONS o SOLENOID IDENTIFICATION TABLE
SELF TEST # SEQUENCE
1 TOPTHUMPERBUMPER
2 LEFTTHUMPERBUMPER
3 RIGHTTHUMPERBUMPER
4 BOTTOMTHUMPERBUMPER
5 LEFTSLINGSHOT
6 RIGHTSLINGSHOT
7 RESETDROPTARGET
8 KICKERLEFT
9 KICKERRIGHT
10 TELEPORTLEFT
11 TELEPORTRIGHT
12 KICKTOPLAYFIELD
13 RESERVEDFORGERMANUSE
14 OUTHOLE
15 KNOCKER
16 FLEXSAVERIGHT(RIGHTGATE)
17 FLEXSAVELEFT (LEFTGATE)
18 FLIPPER o SWITCH ASSEMBLYIDEHTlFICATION TABLE
SELF TEST # SEQUENCE
1 DUSTt LEFT(TARGET)
2 DUST2 (TARGET)
3 DUST3 (TARGET)
4 DUST4 RIGHT(TARGET)
5 CABINETLEFT
6 CREDIT(CABINET)
7 CABINETRIGHT
8 OUTHOLE
9 COINSRIGHT(DOOR)
10 COINS LEFT(DOOR)
11 COINSMIDDLE(DOOR)
12 LEFTRETURNlANE
13 RIGHTRETURNLANE
14 SLAM (DOOR)
15 TILT(CABINET)
16 REBOUND
17 TOPBUMPER
18 LEFTBUMPER
19 RIGHTBUMPER
20 BOTTOMBUMPER
21 LEFTSLINGSHOT(X2)
22 RIGHTSUNGSHOT (X2)
23 DRAGONLAIRLEFT
24 DRAGONLAIRRIGHT
25 SHIELD 1 LEFT (TARGET)
26 SHIELD2 MIDDLE(TARGET)
27 SHIELD3 RIGHT(TARGET)
28 SWORD1 LEFT(TARGET)
29 SWORD2 MIDDLE(TARGET)
30 SWORD3 RIGHT(TAR6ET)
31 TELEPORTLEFTEMPTY
32 TELEPORTLEFTLOADED
33 DROPTARGETBOTTOM
34 DROPTARGETMIDDLE
35 DROPTARGETTOP
36 SKILL 1 BOTTOM
37 SKILL 2 MIDDLE
38 SKILL 3 TOP
39 TELEPORTRIGHTEMPTY
40 TELEPORTRIGHTLOADED
41 LEFTRETURNLANE
42 LEVELSWITCH
43 MIWON SWITCH
44 RESTOREWEAPONS
45 NOTUSED
46 OUTHOLE1 LEFT
47 OUTHOLE2 MIDDLE
48 OUTHOLE3 RIGHT
"NOTE: SEQUENCENUMBERSSHOWNHEREAREUSED
AS AN AID IN LOCATINGFACULTYSOLENOIDOR
SWITCHON AGURE lIa.
"NOTE:BAlL EJECTVECTORSHOWNFOREACHTELEPORT
DROPTARGETASSEMBLY.BAll WIll EXITAS
INDICATEDON FIGURElIa.
