SWITCH LOCATIONS (continued)
•
Race
Track
Assy .
•
0
@
@
Item Switch Part
Description
Item Switch Part
Description
No.
No.
No.
No.
42 A-16908
ZA-1 Top Entry (LED)
64 SW-l1A-37
Bottom Jet
A-16909
(Transistor)
65 SW-llA-37
Right Jet
43 A-16908
Skid Pad
Entry
(LED)
66 5647-12693-19
Left
Rollover
A-16909
(Transistor)
67 5647-12693-19
Middle
Rollover
44 5647-12693-21
Skid Pad
Exit
68 5647-12693-19
Right
Rollover
45 5647-12693-21
Route 66 Exit
71 A-18951
ZR-1 Full Left
46 A-19294
Left Standup 3
72 A-18951
ZR-1 Full Right
47 A-19294
Left Standup 2
73
Not Used
48 A-19294
Left Standup 1
74
Not Used
51 A-19141
Left Race Start
75 5647-12693-31
ZR-1 Exit
52 A-19141
Right Race Start
76 5647-12133-11
ZR-1 Lock Ball 1
53
Not Used
77 5647-12693-53
ZR-1 Lock Ball 2
54
Not Used
78 5647-12693-54
ZR-1 Lock Ball 3
55 A-18821
Left Race Encoder
81 A-16816-4
Standup Million
56 A-18821
Right Race Encoder
82 A-17226-4
Skid Pad Standup
57 5647-12693-21
Route 66 Kickout
83 A-18019-4
Right Standup
58 5647-12693-13
Skid Route 66 Exit
84 SW-1A-120
Right Rubber
61 SW-1A-114
Left Slingshot
85
Not Used
SW-1A-120
86 SW-1A-120
Jet Rubber
62 A-17612
Right Slingshot
87 5647-12693-19
Left
Outer
Loop
•
A-17613
88 5647-12693-19
Right Outer Loop
63 SW-11A-37
Left Jet
*NotShown
