50050-88
Backbox Assembly
I
I
Ribbon Cables
Item Part Number
Description
Item Part Number
Designator
01-6645
Venting Screen
11 5795-12653-03 Ribbon Cable, 34-pin, 3"
2 B-1 0686-1
Knocker Assembly
12 5795-12653-12 Ribbon Cable, 34-pin, 12"
3 A 14092-7
WPC '95 Mounting Plate Assy.
13 5795-12838-25 Ribbon Cable, 14-pin, 25"
4 A-20028
WPC '95 Power Driver PCB
14 5795-10938-15 Ribbon Cable, 26-pin, 15"
5 A-20516-50050
WPC '95 Audio Visual PCB
6 A-20 119-50050
WPC '95 CPU PCB
Miscellaneous Parts
7 04-10276-50050
Backbox, Wood
8 A-20245
Speaker/Display Assembly
08-7456
Backbox Glass: 27 x
18-718"
a)
555-12924-00
Speaker Tweeter, 15w, 40
20-9718
Wing Screw, 3/8-16 x 2"
b)
5555-1 2856-00
Speaker,
5-1/4",
25w, 40
31-1357-50050 Screened Translight
c)
5045-12914-00
Capacitor, 1OI-lfd., 50v (±20%)
d)
5901-12784-00
Dot Matrix Display/Driver Board
Backbox Cables
9 A-13379
Lock & Plate Assembly
10 500S0-IN
Insert Assembly
H-20479
Dot Matrix Display Power Cable
H-20477
Logic Power Cable
H-20478
Secondary Cable
H-20723
Insert Cable
11
t
2-2
