Power Driver Board Continued ...
J W8-Not Used
Jl09-1 Blue-Brown, solenoid 2S drive to flash lamp
Jl09-2 Blue-Red, solenoid 26 drive to flashlamp
Jl09-3 Blue-Orange, solenoid 27 drive to flashlamp
Jl09-4 Blue-Yellow, solenoid 28 drive to flashlamp
Jl09-S N/C
Jl09-6 N/C
Jl09-7 Key
Jl09-8 N/C
Jl09-9
N/C
JllO- Not Used
Jlll-l
Black-Brown, solenoid 17 drive to flashlamp
J 111-2 Black-Red, solenoid 18 drive to flash lamp
J 111-3 Black-Orange, solenoid 19 drive to flashlamp
Jlll-4 Black-Yellow, solenoid 20 drive to flash lamp
J 111-S Blue-Green, solenoid 21 drive to flash lamp
J 111-6 Blue-Black, solenoid 22 drive to coil
Jlll-7 Blue-Violet, solenoid 23 drive to coil
Jlll-8 Blue-Gray, solenoid 24 drive to coil
.n n-s
Key
J 111-1 0 Red-Orange, tieback diode
Jl11-11 Red-Orange, loop from Jl11-10
Jlll-12 Red-Orange, loop from Jl11-11
Jt
t t-ts Red-Orange, tieback diode
J 112-1
J112-2
J112-3
J112-4
J 112-S
J112-6
Jll2-7
J 113-'
Jl13-2
J 113-3
Jl13-4
Jl13-S
Jl13-6
Jl13-7
Jl13-8
Jl13-9
Black-Brown, solenoid 17 drive to insert panel
N/C
N/C
Key
Black-Yellow, solenoid 20 drive to insert panel
Blue-Green, solenoid 21 drive to insert panel
N/C
Brown-Black, solenoid 9 drive to coil
Key
Brown-Red, solenoid 10 drive to coil
Brown-Orange, solenoid 11 drive to coil
Brown-Yellow, solenoid 12 drive to coil
Brown-Green, solenoid 13 drive to coil
Brown-Blue, solenoid 14 drive to coil
Brown-Violet, solenoid lS drive to coil
Brown-Gray, solenoid 16 drive to coil
Jl14- Not Used
JllS- Not Used
Jl16-1 Violet-Brown, solenoid 1 drive to coil
Jl16-2 Violet-Red, solenoid 2 drive to coil
Jl16-3 Key
J 116-4 Violet-Orange, solenoid 3 drive to coil
Jl16-S Violet-Yellow, solenoid 4 drive to coil
J116-6 Violet-Green, solenoid S drive to coil
J116·7 Violet-Blue, solenoid 6 drive to coil
J116-8 Violet-Black, solenoid 7 drive to coil
J 116-9 Violet-Gray, solenoid 8 drive to coil
Jl17- Not Used
J118- Not Used
J 119-1 Red-Green, +SOV to lower right flipper coil
J 119-2 Red-Green, loop from J 119-1
J119-3 Key
J119-4 Red-Blue, loop from J119-S
J 119-S Red-Blue, +SOV to lower left flipper coil
J 119-6 Red-Violet, +SOV to upper right flipper coil
J 119-7 Red-Violet, loop from J 119-6
J 119-8 Red-Gray, +SOV to upper left flipper coil
Jl19-9 Red-Gray, Loop from Jl19-8
J120-1 Orange-Gray, holding, upper left flipper
J120-2
N/C
J120-3 Yellow-Gray, power, upper left flipper coil
J120-4 Orange-Violet, solenoid 34 drive to coil
J120-S N/C
J120-6 Yellow-Violet, solenoid 33 drive to coil
J120-7 Orange-Blue, holding, lower left flipper coil
J120-8
N/C
J120-9 Yellow-Blue, power, lower left flipper coil
J120-10 Key
J120-11 Orange-Green, holding, lower right flipper coil
J120-12
N/C
J120-13 Yellow-Green, power, lower right flipper coil
J121-Not Used
J122-1 Key
J122-2
N/C
J122-3 Yellow-Gray, lamp column 8 to cabinet
J123-1 Yellow-Brown, lamp column 1 to playfield
J123-2 Yellow-Red, lamp column 2 to playfield
J123-3 Yellow-Orange, lamp column 3 to playfield
J123-4 Yellow-Black, lamp column 4 to playfield
J123-5 Yellow-Green, lamp column S to playfield
J123-6 Yellow-Blue, lamp column 6 to playfield
J123-7 Yellow-Violet, lamp column 7 to playfield
J123-8 Key
J123-9 Yellow-Gray, lamp column 8 to playfield
J124-Not Used
J12S-1 Red-Brown, lamp row 1 to playfield
J12S-2 Red-Black, lamp row 2 to playfield
J12S-3 Key
J12S-4 Red-Orange, lamp row 3 to playfield
J12S-S Red-Yellow, lamp row 4 to playfield
J12S-6 Red-Green, lamp row S to playfield
J12S-7 Red-Blue, lamp row 6 to playfield
J12S-8 Red-Violet, lamp row 710 playfield
J 12S-9 Red-Gray, lamp row 8 to playfield
J126-1 N/C
J126-2 N/C
J126-3 Key
J126-4 N/C
J12S-5 N/C
J12S-S
N/C
J126-7 Red-Blue, lamp row 6 to cabinet
J126-8 Red-Violet, lamp row 7 to cabinet
J126-9 Red-Gray, lamp row 8 to cabinet
3-27
