T.18 MAGNET TEST CONTINUED ...
For the Magnet tests, the display shows:
• Status of the left loop magnet
• Status of the ramp magnet
• Status of the Ringmaster magnet
Left Loop Magnet
To test the left loop magnet, roll the ball up the left loop. The magnet should catch the ball, and
let it roll into the Juggler Saucers. The saucers will kick the ball out.
If the magnet does not activate on screen, the left loop enter switch (switch 48) doesn't work.
Check the switch and try again. (Note: A broken wire on the same switch row or column could
cause this switch not to work.)
If the magnet activates on screen but the physical magnet does not turn on, check the fuse and
magnet wiring. Check the magnet in Solenoid test too.
If the diverter has not been disabled by the adjustment, then it will
be
open (active) during the
test. Roll the ball up the right loop to test the magnet as well. Careful, the ball may fall into the
trough behind the display, the popper will kick the ball out.
If the magnet does' not activate on screen, the left loop upper switch (switch 15) doesn't work.
Check the switch and try again. (Note: A broken wire on the same switch row or column could
cause this switch to not work.)
If the magnet activates on screen but the physical magnet does not turn on, check the fuse and
magnet wiring. Check the rnaqnetin Solenoid test too.
Ramp Magnet
To test the ramp magnet, roll the ball up the main ramp. The magnet should catch the ball, and
let it drop into the ramp lockup (which will release the bali).
If the magnet does not activate on screen, the ramp magnet switch (switch 64) doesn't work.
Check the switch and try again. (Note: A broken wire on the same switch row or column could
cause this switch to not work.)
If the magnet activates on screen but the physical magnet does not turn on, check the fuse and
magnet wiring. Check the magnet in Solenoid test too.
.
,~
il!,
"
;l(
ii!
ljl
if
""
If the magnet does not activate on screen, the WOW targets (switch37) do not work. Check all
::
three targets and try again (Note: A broken wire on the same swltchrow-or-columncoufd·-cause--------·-----lj··
this switch to not work.)
i
Ringmaster Magnet
To test the Ringmaster magnet, make sure the Ringmaster is in the DOWN position and roll the
ball into the WOW targets. The magnet should grab the ball, hold it, and then throw it away. Note:
The magnet will occasionally miss the ball, especially fast balls, and if the magnet is hot. This is
normal.
.
If the magnet activates on screen but the physical magnet does not turn on, check the fuse and
magnet wiring. Check the magnet in Solenoid test and the Ringmaster test too.
