Power Driver Board Continued ••.
J118-1
N/C
J118-2 VIO-RED For solenoid #2 to insert coil
J109-1 BlU-BRN For solenoid #25 drive to plyfld flasher
.J118-3
N/C
J109-2 BlU-RED For solenoid #26 drive to plyfld flasher
J11B-4 KEY
J109-3 BlU-ORG For solenoid #27 drive to plyfld flasher
J118-5
N/C
J109-4 BlU-YEl
For solenoid #28 drive to plyfd flasher
J109-S
N/C
J119-1 RED-GRN +SOV to lower right flipper coil.
J109-6 NlC
J119-2 RED-GRN loop from J119-1.
J109-7 KEY
J119-3 KEY
J109-8 N/C
J119-4 'RED-BlU loop from J 119-5.
J109-9
N/C
J119-5 RED-BlU +SOV to lower left flipper coil.
J119-6 RED-VIO +50V to solenoid #33 for Popper
J110-1 BRN-WHT For Solenoid #37 drive to Neon
J119·7 RED-VIO +50V to solenoid #34 for Diverter Hold
J11D-2
KEY
J11S-8 RED-GRY +50V to solenoid #35 for Ringmaster Mgt
J110-3 ORG·WHT NfC
J119·9 RED-GRY +50 V to solenoid #36 for Upper Post
J110-4 YEl·WHT For solenoid #38 drive to Motor PC Board
J110-S BlU-WHT For solenoid #39 drive Eddy Sensor Brd J120-1 ORG-GRY For sol. #36 hold drive to Upper Post
J120-2
N/C
J111-1 BlK-BRN For solenoid #17 drive to playfield flasher.
J120-3 VEl-GRY For sol. #35 power drive to Ringmaster Mgt
J111-2 BlK-REO For solenoid #18 drive to playfield flasher.
J120·4
N/C
J111-3 BlK-ORG For solenoid #19 drive to playfield flasher.
J120-5 ORG·VIO For sol. #34 hold drive to Diverter Hold
J111-4 BlK-VEl
For solenoid #20 drive to playfield flasher.
J120-6 YEl-VIO For sol. .#33 power drive to Popper
J111-5 BlU-GRN For solenoid #21 drive to playfield flasher.
J120-7 ORG-BlU For sol. #32 hold drive to low left flipper.
J111-6 BlU-BlK For solenoid #22 drive to playfield flasher.
J120-B
N/C
J111-7 BlU-VIO For solenoid #23 drive to playfield flasher.
J120-9 YEl-BlU For sol. #31 power drive to low left flipper.
J111-8 BlU-GRY For solenoid #24 drive to playfield flasher.
J12D-10 KEY
J111-9 KEY
J120-11 ORG-GRN For sol. #30 hold drive to low right flipper.
J11HO
N/C
J120-12 NfC
J111-11
N/C
J12D-13
YEl-GRN For sol. #29 power drive to low right flipper.
J111-12
N/C
J11H3
N/C
J121
NOT USED
J112-1 N/C
J122-1 KEY
J112-2
N/C
J122-2 NlC
J112-3
N/C
J122-3 YEl-GRY For lamp column #8 to cabinet.
J112-4 KEY
J112-S
N/C
J123-1 YEL-BRN For lamp column #1 to playfield.
J112-6 BlU-GRN For solenoid #21 drive to insert flasher.
J123-2 YEl-RED For lamp column #2 to playfield.
J112-7
N/C
J123-3 YEL-ORG For lamp column #3 to playfield.
J112-8
N/C
J123-4 YEL-BlK For lamp coiumn #4 to playfield.
J112-S BlU-GAY For solenoid #24 drive to insert flasher.
J123-5 YEL-GRN For lamp column #5 to playfield.
J123-6 YEl-BlU For lamp column #0 to playfield.
J113
NOT USED
J123-7 YEL-VIO For lamp column #7 to playfield.
J123-8 KEY
J114-1 BRN-BlK For solenoid #9 drive to playfield coil.
J123-9 YEl-GRY For lamp column #8 to playfield.
J114-2 KEY
J114-3 BRN-RED For solenoid #10 drive to playfield coil.
J124
NOT USED
J114-4 BRN-ORG For solenoid #11 drive to playfield coil.
J114-5 BRN-YEl
For solenoid #12 drive to playfteld coil.
J125·1
N/C
J114-6 BRN-GAN For solenoid #13 drive to playfield coil.
J12S·2
N/C
J114-7 BRN-BLU For solenoid #14 drive to playfield coil.
J12S-3 KEY
J114-8 BRN-VIO For solenoid #15 drive to playfield coil.
J125-4
N/C
J114-9 BRN-GRY For solenoid #16 drive to playfield coil.
J12S-5
N/C
J12S-6
N/C
J115
NOT USED
J12S-7 RED-BLU For lamp row #6 to coin door board J3-S.
J12S-8 RED-VIO For lamp row #7 to coin door brd J3-10.
J116-1 VIO-BRN For solenoid #1 drive to playfield coil.
J125-9
REO-GRY For lamp row #8 to coin door brd J3-11.
J116-2
NfC
J116-3 KEY
J126-1 REO-BRN For lamp row #1 to playfield.
J116-4 VIO·ORG For solenoid #3 drive to playfield coil.
J126·2 RED·BlK For lamp row #2 to playfield.
J116-5 VIO-YEL For solenoid #4 drive to playfield coil.
J126-3 KEY
J116-6 VIO-GRN For solenoid #S drive to playfield coil.
J126-4 RED-ORG For lamp row #3 to playfield.
J116-7 VIO-BlU For solenoid #6 drive to playfield coil.
J126-5 RED-YEL For lamp row #4 to playfield.
J116-8 VIO-BlK For solenoid #7 drive to playfield coil.
J126·6 RED-GRN For lamp row #5 to playfield.
J116-9 VIO-GRY For solenoid #8 drive to playfield coil.
J126-7 RED-BlU For lamp row #6 to playfield.
J126-8 RED-VIO For lamp row #7 to playfield.
J117
NOT USED
J126-9 RED-GAY For lamp row #8 to playfield.
