Coin Door Interface Board
A-20580
J5
J6
10
0 0
*
0 0 0 0 0 0 0 0
01
10 0
0 0 0 0 0 0
0
0 0
0
0
*
01
J1-1 ORG·GRY Dedicated sw row #8 from CPU J205·9.
J6
NOT USED
J1·2 ORG·VIO Dedicated sw row #7 from CPU J205·8.
J1-3 ORG·BlU Dedicated sw row #6 from CPU J205· 7.
J7-1 YEL-GRY lamp column #8 to cabinet.
J1-4 ORG-GRN Dedicated sw row #5 from CPU J205-6.
J7-2
N/C
J1-5 ORG-YEl
Dedicated sw row #4 from CPU J205-4.
J7-3 RED-BlU lamp row #6 to cabinet.
J1-6 ORG-BlK Dedicated sw row #3 from CPU J205·3.
J7-4 RED-GRY lamp row #8 to cabinet.
J1-7 ORG·RED Dedicated sw row #2 from CPU J205~2.
J7·5 KEY
J1·8 ORG-BRN Dedicated sw row #1 from CPU J2Q5-1.
J7·6 GRN-BRN Switch column #1 to cabinet.
J1·9 KEY
J7·7
N/C
J1-10 BlK
Ground from CPU J205·10
J7-B N/C
J1-11 ORG·WHT Switch enable from CPU J205-12.
J7-9
N/C
J7-10 WHT-BRN Switch row #1 to cabinet
J2·1 BlK
Ground from Power Driver board J141-3.
J7·11 WHT·ORG Switch row #3 to cabinet.
J2·2 GRY-YEl
+
12VAC from Power Driver board J141-2.
J7-12
N/C
,J2-3 WHT·VIO 6.8VACfrom Power Driver board J104-1.
J7-13
N/C
J2-4 KEY
J2-5 VIO
For G.l. from Power Driver board J 104-3.
J8·1 WHT
Switch row to cabinet for Slam tilt.
J2-6
N/C
J8-2 KEY
J2·7 BlK-WHT Signal for coin meter from Power Driver
J8-3 GRN
Switch column to cabinet for Slam Tilt. .
board J139-S.
J9·1 WHT-YEl
Switch row #4 to Plumb Bob Tilt.
J3·1 GRN-BRN Switch column #1 from CPU J212·1.
J9-2 KEY
J3-2 GRN-RED Switch column #2 from CPU J212·2.
J9-3 GRN-BRN Switch column #1 to Plumb Bob Tilt.
J3-3 WHT·BRN Switch row #1 from CPU J212-4.
J9-4 WHT·RED Switch row #2 to Interlock Switch.
J3-4 WHT-RED Switch row #2 from CPU J212·5.
J7-5 GRN-RED Switch column #2 to Interlock Switch.
J3·5 WHT-ORG Switch row #3 from CPU J212-6.
J3-6 WHT-YEL Switch row #4 from CPU J212-7.
J10 Ribbon cable To cash flow mechanism (if used).
J3·7 KEY
J3-8 YEl·GRY Lamp col #8 from Pwr Drvr brd J122-3.
J3·9 RED-BlU Lamp row #6 from
PWf
Drvr brd J125·7.
J3-10 REO-VIO lamp row #7 from Pwr Drvr brd J 125-8.
J3·11 RED·GRY lamp row #8 from Pwr Drvr brd J12S-9.
J4
NOT USED
J5-1 VIO
Return to coin door.
J5·2 WHT·VIO 6.8VAC for G.I. to coin door.
J5-3 BlK
Ground to coin door.
J5-4 ORG·BRN Dedicated switch row #1 to coin door.
J5-S ORG-RED Dedicated switch row #2 to coin door.
J5·6 ORG-BlK Dedicated switch row #3 to coin door.
J5-7 ORG-GRN Dedicated switch row #5 to coin door.
JS-8 ORG·BlU Dedicated Switch row #6 to coin door.
J5-9 ORG-VIO Dedicated switch row #7 to corn door.
J5-10 KEY
J5-11 ORG·GRY Dedicated switch row #8 to coin door.
J5-12 GRN·AED Switch column #2 to coin door Slam Tilt.
J5·13 WHT-BRN Switch row #1 to coin door Slam Tilt.
3-25
