Shooter Lane Kicker Assembly
'I
L
",
~
Item Part Number
1 04-10210.4
2 04-10211.5
3 04-10461
4 4010-01066-06
5 4701-00004-00
6 AE-23-800
7
03-7066
8 01-8413
9 10-128
10
A-15847
11 4701)..00104-00
12
12-6227
13
4006-01003-05
14 01-8600
15 5647-12693-68
16
4002-01105-08
17 H-16437
18 5070-09054-00
19 H-19523
Description
Kicker Crank
Coil Mounting Bracket
Flipper Stop Bracket Assembly
Cap Screw, #10 x
3/8"
Lock Washer
#10
Split
Coil Assembly
. Coil Tubing
Coil Mounting Bracket
Spring
Flipper Link Assembly
Flat Washer,
23/64
x
Y2
x
16ga.
Hair Pin Clip
Mach. Screw, 6-32 x 5/16"
Insulator
Mini·Micro Switch
Mach. Screw, 2-56 x
W'
Cable
Diode
Cable
