A-9415-2
Jet Bumper Coil Assembly
r-.••.••...••.
"
,
I
I
:
I
I
I
:
I
I
,
I
:
I
I
I
I
:
I
I
I
I
:
I
I
I
:
I
I
I
I
:
I
I
I
:,
"
,
"
,
"
I
" I
'"
Item Part Number
Description
1
04-10888
Bracket & Stop Assembly
2
01-1747
Coil Retaining Bracket
3
01-5492
Armature Link, Steel
4
01-5493
Armature Link, Bakellne
5
02-3406-1
Coil Plunger
6
10-326
Armature Spring
7
AE-26-1200
Coil Assembly
8
4006-01017-04
Mach. Screw, 6-32 x
1/4"
9
03-7066
Coil Tubing
10 H-19523
Cable
Associated Parts: (
Not Shown)
11 8-12030-2
Leaf Switch Assembly.
a)
A-16443
Switch & Diode Assembly
b)
01-1168
Switch Mounting Bracket
c)
01-3670
Switch Plate
d}
03-7395
Switch Actuator
e)
4005-01003-12
Mach. Screw, 5-40 x 3/4"
f)
4405-01117-00
Nut
5-40 Hex.
2-19
