Item Part Number .
Description
~.
~
16
4006-01 005"06 Mach. Screw, 6-32 x 3/S"
17
4406-01117"00 Nut 6-32 Hex.
is
A-15848-R
Crank Link Assembly, Right
a)
A"17050"R
Flipper Crank Assembly, Right
1.
01-11764"R
Flipper Crank, Right
2.
4700"00107 -01 Mod-Crank Washer
3.
RM-23"06
H.S. Tubing 14"
4.
4010-01066"20 Mach. Screw, 10-32 x 1-1/4"
Item Part Number
Description
5.
4410-01127"00 Nut, 10-32 Hex.
6.
4700-00107-00
FW: 13/64 x 5/8 x 12ga.
1
A-14877-R
Flipper Base Assembly, Right
7.
4701-0000~00
Lockwasher #10 Split
2 SW-1A-194
Switch Assembly
8.
01-9376
Spring Retainer Bracket
3 4701-00002-00
Lock Washer #6 Split
b)
A-15847
Flipper Link Assembly
4 4105-01019-10
Sh. Metal Screw, #5 x 5/S"
c)
02-4676
Link Spacer Bushing
5 4008-01079-05
Mach. Screw, 8-32 x
5/16"
d)
401 0-01086-14 Cap Screw, 10-32 x 7/S"
6 4701-00003-00 Lock Washer #S Split
e)
4700-00023"00
Flat Washer,
5/8
x 13/64 x 16ga.
7 01-9375
Switch Mounting Bracket
f)
4701-00004-00
Lock Washer #10 Split .
8
20-6516
Speednut, Tinnerman
g)
4410-01132-00
Nut 10-32 ESN
9 4010-&l066-06
Gap Screw; 10-32x3/S
n
19
23~6577'
Bumper
Plug,
5/8"
10 4701-00004-00
Lock Washer #10 Split
20
03-7568
Flipper Bushing
11 A-12390
Flipper Stop Assembly
21
03-7066-5
Coil Tubing
12 FL-11630
Flipper Coil, Red
13 01-7695-1
Solenoid Bracket
Associated Parts: (Not Shown) .
14 4006-01017-04
Mach. Screw, 6-32 x
1/4"
23-6695
Flipper Ring
15
10-364
Spring
20-10110-5
Flipper Bat w/Shaft
Flipper Notes ...
1. Each Ripper Assembly
is
mounted beneath the playfield, in conjunction with the Plastic Flipper
&
Shaft, and Flipper Rubber on the upper side of the playfield.
2. With the flipper, in the non-ectiveted position, the E.O.S. Switch contacts must have a gap of .062 (:t.015) inch. When flipper
is
activated switch must close.
3. Any adjustment of the EO.S. switch must be made at a minimum distance
of
0.25 inch from the switch body.
4. Longer blade of E.
0.
S. switch must be made straight. Gap adjustment is done by adjusting snoner blade.
5. All moving elements of the assembly must operate freely without any evidence of binding.
6. Apply Loctite
rM
245
when reattaching screws to the Flipper Stop Assembly, the Solenoid Bracket, and the Flipper Bushing.
2-15
