TO REMOVE RINGMASTER'S HEAD.
The Ringmaster has very few parts that need service. A flasher and magnet coil are located within his
head and only three micro switches are needed. You can remove the head for cleaning or the replace
the flasher bulb as shown below.
m
ReMove #10 scr ew
~ ~ Lift Meto.l lid.
~,
"
-,
"
rr5\
Re pl o.ce flo .sher
\ 0
or Mo .gnet
0 .5
re quired
FIG. 3
Mo ve heo.d to up po sit ion !
ReMove (2) #8 screw s
Fr-om
the bo.ck side
g.,
pull off he o.d ,
@
Replo.ce o .ll po.rts
so the he o.c Iis
tight
o. .nclflush,
