SCORE DRUM UNIT
WITH PRINTED CIRCUIT AND CONTACT RING
,
ZERO SWITCHES---.,
POSITION
SWITCH--~
8-26
800
,
PROPER LUBRICATION WILL INSURE A LONGER
LASTING AND BETTER OPERATING UNIT.
PO INTS TO BE LUBRICATED ARE THE THREE POSTS
ON WHICH THE NYLON PARTS ROTATE, EACH TOOTH OF THE
RATCHET, ALSO THE (2) DRIVE PAWL GUIDE SLOTS,
INDICATED BY
t*).
LUBRICATION:
DO NOT PUT LUBRICANT ON
END OF STROKE
SWITCH
ARMATURE
SWITCH ADJUSTMENT
AT "0" OR INDEX POSITION ALL
SWITCHES ARE OPEN AS SHOWN.
OPEN
OPEN
OPEN
AT 1st. TO 8th· POSITION TOP
SWITCHES ARE CLOSED - BOTTOM
SWI TCH REMAINS OPEN.
?
i
=
CLOSED
{ - ~~!==::
CLOSED
<at
OPEN
AT 9th POSITION ALL SWITCH ES
~ ARE CLOSED AS SHOWN
CLOSED
CLOSED
CLOSED
13
