WHAT TO DO IF:
1. Lights are out, game is inoperative:
a. Check A.C. cord and plugs for breaks, cuts or other damage.
b. Check fuses, located behind cash box.
c. Check master switch, located under front of cabinet.
d. Check plugs and jacks for proper installation.
2. Lights are out, game operates:
a. Check two switches on Lock Relay: Blue-Yellow-White to Green-
Yellow-White, and Brown-Yellow-White to Green-Yellow-White.
b. Check 10 AMP fuse-Blue wire, and 15 AMP fuse-Brown wire.
3. Lights are on, but all coins are rejected:
a. If Coin Lockout Coil (located on front door) is not energized,
check the Last Position Break Switch on Replay UnIt: Black
and Black-Red. Check switch on Index Cam; Green-Red and
Yellow. Check switch on Reset Relay; Green-Red and White-Gray.
b. If Coin Lockout Coil.!.!
enez-gd
aed , check the wire forms
actuated by the armature on this cull. Then check the slug
re jector.
4. Game resets but Game Over Relay trips in~ediately:
a. Check switch on Lock Relay Blu-Red and Yellow.
b. Check Ball Count Unit Reset Coil.
c. Check Ball Count Unit wiper fingers for proper resetting.
5. Game is over, replays are indicated, but the Replay Button fails
to start a new game:
a. Check Make and Break Switch on Index Cam (Green-Red and Yellow).
b. Check switch on Reset Relay (Green-Red and White-Gray).
c. Check Reply Button Switch.
d. Check Replay Unit Zero Switch, White-Orange and White-Brown.
e. Check switch on Game Over Relay (White-Brown and White-Blue).
f. Check Replay Relay Coil.
6.
Super Bonus Drum does not re~et to zero when ball leaves
playfield:
d.
Sequence of operatIon - - - Outhole Switch energizes
Outhole Relay.
Switch "C·Iof Outhole Relay energizes Bonus Reset Relay.
Bonus Reset Relay is held in thru Zero Position Switch
on Bonus Drum Unit.
Switch "B" on Bonus Reset Relay continues to run Score Hotor.
Switch SIC"on Bonus Reset Relay pulses Bonus Drum Unit,
thru Impulse Cam Switch "Bn and zero position Switch on
Bonus Drum Unit (BlacK-Red and Red-BIu).
7. Disappearing Post does not function properly:
a. Latch and Trip coils are controlled by Number Match Unit
DiSC, and Switch on 1 Point Relay.
b. For Latch COil, check Red-Green to Red-Blu on Number Match Disc.
c. For Trip Coil, check Red-Yellow to Red-Blu on Number Match Disc.
d. Check switch on I Point Relay, Yellow and Red-Blu.
