Parts Information
1!L11atk
lk-nigbt
2000
UNIQUE PARTS LIST
Part No.
Description
Part No.
Description
A-10231-1
PCB Mount Socket & Bulb
D-12702·R-1 Flipper Assembly·Right
A-11538-1
Stand up Switch & Bracket Assembly
D-12768
Bottom Arch Assembly
A·11539-1
Kicker Switch Assembly-Right
A·12463
Motor Cam Assembly
H-12190-563 Main Backbox Cable
A·12640
Ball Gate Assembly
H-12192-563
Black Knight
Cabinet Cable
A·12664
Crank Assembly
H-12680
Playfieid Lamp Cable
A-12670
Kicker Mounting Plate Assembly
H-12681
Playfieid Lamp Cable
A·12687
Sub-Mini Switch Assembly
H-12682
Playfield Solenoid Cable
A·12688
Sub-Mini Switch Assembly
H-12683
Upper Playfield Cable
A-12692
Ball Guide Assembly
H-12684
Insert Cable
A·12767
Playfield Holder Bracket Assembly
H-12685
Ramp Switch Cable
A-8447·1
Magna Coil & Bracket Assembly
H-12690
3-Bank Drop Target Switch Cable
H-12726
Auxiliary Lamp Cable
B-12465
Motor Assembly
B-12599
Ball Turnround Assembly
01-9122
Ramp Flap
B-12636
Ramp Assembly
01-9145
Ball Deflector
B-12637
Ramp Sub-Assembly
01-9151
Ball Guide Baffle
B-12639-L
Hinge Bracket Assembly-Left
01-9168
Playfield Holder Bracket-Right
B-12639-R Hinge Bracket Assembly-Right
01-9177
Playfield Support Bracket
B-12649
Ball Guide Assembly
01-9182
Playfield Prop Arm Ctch
B-12650
Ball Guide Assembly
B-12657
Ball Guide Assembly
03- 7960-563 Playfield Mylar
B-12658
Ball Guide Assembly
03-8204-9
Light Hood-Double, Tr-Red
B-12659
Ball Guide Assembly
03-8205-9
Light Hood-Single, Tr-Red
B-12665
Kicker Assembly-Nylon
B-12671
Kicker Assembly
10-407
Extension Spring
B-12693
Left Wire Gate Assembly
B-12695
Flipper Ball Guide Assembly
11-902-A
Wood-Rail, Lower
B-12708
Ball Gate & Switch Assembly
11-902-B
Wood-Rail, Lower
B-12720
Ball Gate
&
Switch Assembly
11-902-C
Wood-Rail, Lower
B-12725
Switch
&
Cable Assembly
11-902-D
Wood-Rail, Lower
B-12743
Flipper Ball Guide Assembly-Left
11-902-E
Wood-Rail, Lower
11-903-A
Wood-Rail, Upper
C-12464
Moving Target Assembly
11-903-B
Wood-Rail, Upper
C-12519
Bottom Playfield Lamp Assembly
11-903-C
Wood-Rail, Upper
C-12520
Left Side Playfield Lamp Assembly
11-903-D
Wood-Rail, Upper
C-12638
3-Switch Mount PCB Assembly
C-12646
Upper Playfield Interconnect Board Assy
12-6826
Ball Pop Wire Form
C-12652
Ball Guide Assembly
12-6827
Return Wire Form
C-12653
Ball Guide Assembly
12-6828
Left Wire Cage
C-12654
Ball Guide Assembly
12-6830
Connect Wire Ramp
C-12655
Ball Guide Assembly
12-6831
Exit Wire Ramp
C-12656
Ball Guide Assembly
C-12674
Top Ramp Assembly
20-9589-24
Slit H/Sleeve 24"
C-12700
6-Speaker Lamp Assembly
C-12723
Upper Playfield Top Lamp Assembly
31 -1002A-563 Lower Playfield (Screened)
C-12724
Upper Playfield Bottom Lamp Assembly
31 -1002B-563 Upper Playfield (Screened)
31 -1006-563 Playfield Plastics
D-11581-563 Audio Sound Board Assembly
31 -1008-563 Bottom Arch (Screened)
D-11883-563 CPU System 11B Assembly
31 -1009-563 Shooter Gage Plate (Screened)
D-12313-563 Master Interconnect Board Assy
31-1422-563
Speaker Grill (Screened)
D-12503
Center Playfield Lamp Assembly
31-1457-563
Black Knight
Backglass
D-12660
Ball Guide Assembly
31 -1463-563 Drop Target Decal
D-12696
Speaker Display Assembly
lHadt 1ttigbt 62
