Parts Information
Moving Target Assembly
pIn
C-12464
Item
1A
2A
3A
4A
5A
1)
2)
6A
7A
8A
9A
10A
* 11A
Part No.
03-8028
01-8494
4106-01001-10
23-6534-9
B-12725
A-11177-1
A-11315-3
01-3670-1
4004-01 003-12
4404-01119-00
03-8235
03-8236
4106-01019-10
* Not Shown
Description
Retainer Carrier
Support Bracket
Sh. Metal Screw, #6 x
5/8
Edge Protector
Targets & Cable Assembly
Left Target Assembly
Mid & Rt Target Assembly
Switch Plate (Flat)
Mach. Screw, 4-40
x
3/4
Nut. 4-40 ESNA
Target Guide
Carrier Target
Sh. Metal Screw, #6 x 5/8
Motor Assembly
pIn
8-12465
Item Part No.
1 01-9017
2 B-11571-2
a) 14-7941-3
b) 5791-09111-00
c) 5820-09080-00
3 4701-00003-00
4 A-12463
a) 02-4262
b) 02-4354
c) 02-4355
5 4008-01076-06
6 5647-12073-06
7 4002-01005-06
8 4701-00024-00
9 4008-01005-16
10 4408-01117-00
11 4008-01040-08
12 01-8600
13 5070-06258-00
Description
Motor Mounting Bracket
Motor Sub-Assembly
Motor 11 RPM
3P1396 03-09-2032
PM119002-09-2101
Lockwasher, #8 Split
Motor Cam Assembly
Operating Post
Motor Cam
Switch Actuator Post
Set Screw, 8-32 x 3/8
Snap Action Switchlw Roller
Mach. Screw, 2-56 x 3/8
Lockwasher, #2 Split
Mach. Screw, 8-32 x 1
Nut, 8-32 Hex
Mach. Screw, 8-32 x 1/2
Switch Insulator
Diode, 1N4001, 1.0 A.
