MAINTENANCE INFORMATION
Figure 4 shows the two main lubrication points of the Shooter Lane Feeder. The shaded arrows show
the directions in which the Shooter Lane Feeder and other parts of its related assemblies can be
adjusted for proper operation. Note that the mechanisms of the Eject Hole Arm Assembly is quite
similar to the Shooter Lane Feeder; it has the same lubrication requirements and adjustment
capabilities as the Shooter Lane Feeder.
LUBE
POINTS
TOP VIEW
Figure 4. Adjustments and Lubrication Points, Shooter Lane Feeder.
Because of the functional design (arm-actuated via solenoid plunger operation), the pivot points of the
Left and Right Kickers ("Slingshots") all require lubrication as a regular servicing procedure. Mechanical
adjustments are simple and somewhat similar to the Shooter Lane Feeder. These mechanisms should
also be checked for proper fit (snugly tight) where they attach to the playfield.
Lubrication to ensure proper operation also applies to the target blades of each 3-Bank Drop Target.
Regular maintenance is essential to a game's continuing contribution to the operator's earnings.
