PINBALL GAME ASSEMBL V INSTRUCTIONS
(Continued)
©&'mD©1Nl
Playfield pitch angle adjustments can affect the operation of the plumb bob tilt, inside
the cabinet. The plumb bob weight is among the parts in the cash box; the operator
should install the weight and adjust this tilt mechanism for proper operation, after
completion of the desired playfield pitch angle setting.
7. Move the game into the desired location; recheck the level and pitch angle of the playfield.
8. Verify that the
required number
of balls are installed in the game.
(JU«~i
1~tgbt
2000t
3 bails.)
9. Clean and re-install the playfield cover glass. Prepare the game for player operation.
GAME OPERATION
( WARNING)
After assembly and installation at its site location, this game must be plugged into a properly
grounded outlet to prevent shock hazard, and to assure proper game operation. DO NOT
use a 'cheater' plug to defeat the ground pin on the line cord. DO NOT cut off the ground pin.
