GAME #1092·E BLACK JACK (FIGURE V)
SOLENOID IDENTIFICATION TABLE
SELF-
SELF-
TEST# SOLENOID IDENTIFICATION
TEST
#
SOLENOID IDENTIFICATION
01 OUTHOLE KICKER
02 KNOCKER
- ..03 BEATDEALER SAUCER
64-'~-GJj_IME10
05 CHI~W.O
06 CHIME10~
07 CHIME EXTRA . ~
..
08 LEFT THUMPER BUMPER --...... ,
09 RIGHT fHUMPER BUMPER
10 CENtER THUMPER BUMPER
11 LEFT SLINGSHOT
12 RIGHT SLINGSHOT
13 COIN LOCKOUT
14 Kl RELAY (FLIPPER EN ."......."
c:
SELF-
TEST # SWITCH DESCRIPTION
04 RIGHT LANE
05 SPINNER
06 CREDIT BUTTON
07 TILT (3)
08 OUTHOLE
09 COIN III RIGHT
10 COIN I LEFT
11 COIN" (MIDDLE, IF USED)
16 SLAM (2)
25 CHANGE DEALER TARGET (2)
26 CHANGE PLAYERTARGET (2)
27 HEART LANE
28 SPADELANE
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
SELF·
TEST
II
SWITCH DESCRIPTION
29 DiAMOND LANE
30 CLUB LANE
31 L & R FLIPPER FEEDER LANES
32 BEATDEALER SAUCER
33 RIGHTOUTLANE
34 LEFT OUTLANE
35 10 POINT REBOUND (2)
36 RIGHT SLINGSHOT
37 LEFT SLINGSHOT
38 CENTERTHUMPER BUMPER
39 RIGHT THUMPER BUMPER
40 LEFT THUMPER BUMPER
;
--~
;
