GAME CONTROL LOCATIONS
The On-Off switch is on the bottom of the cabinet near the right front leg.
The Volume Control is on the left inner wall of the cabinet on the tilt mechanisms board. It is accessi-
ble by opening the coin box door.
The Credit switch is a pushbutton to the left of the coin door on the cabinet exterior.
GAME ADJUSTMENT/DIAGNOSTIC SWITCHES.
BANZAI RUN
allows the operator to program
virtually all game adjustments, obtain bookkeeping information, and diagnose problems, using only
three switches mounted on the inside of the coin door and the Credit button beside the coin door.
ADVANCE, AUTO-UPIMANUAL-DOWN,
and HIGH-SCORE RESET are the switches located on the
inside of the coin door. Refer to the Game Status Displays text and the Text/Diagnostic Pro-
cedures for details concerning their operation.
The Memory Protect switch is on the inside frame of the coin door. This interlock switch
must be open to clear bookkeeping totals and to make game adjustments.
It
automatically opens, when the coin door opens.
The CPU Diagnostic switch (SW 2) is the lower switch (of the two switches mounted on
the left edge of the CPU Board) near a large, socketed microprocessor chip. This switch
initiates the Memory Chip Test explained in the TesUDiagnostic Procedures.
The Sound Diagnostic switch (SW 1) is the upper switch of the two mounted on the left
edge of the CPU Board. This switch initiates the Sound Section Test. Refer to the
TesUDiagnostic Procedures.
The Ball Lifter switch is on the lower left of the upper playfield just to the right of the Ball Lifter Magnet.
The Ball Lifter
MUST BE RAISED ENOUGH TO CLEAR THE LOWER PLAYFIELD,
before moving the
upper playfield for servicing.
