XI. PARTS LIST
BABY PAC-MAN #1299
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
AS-3071-12
Bulbs, #555
E-125-73
Fuse, 1 Amp. 3 AG Slow Blow (Playfield Solenoid Protection) .. "
E-133-44
Fuse, 10 Amp (2)(Playfield Lite Protection)
E-133-10
ASSEMBLY COilS
Flipper (2)
AQ-25-500/
34-4500
Left Saucer
AO-27 -1300
Right Saucer
AO-27-13oo
Outhole Kicker
AO-27 -1300
Drop Target Reset
NO-26-1900
Individual Drop Target(3)
CJ-31-2060
PLAYFIELD PARTS
MODULES
MPU A4
AS-3241-1
Transformer & Rectifier A2
AS-2877 -11
Rectifier Board (Part of A2)
AS-2518-132
See Figure
II
REPAIRS PROCEDURES/AIDS
Module
&
Component Replacement
F.O. 560-1
AID (Assistance in Diagnostics)
Kit, used with F.O. 560-1
KIT #485-1
MODULE COMPONENTS
SEE MODULE PARTS LIST
18
