U.9 06 Install 5 Ball
U.9
07 Install 3
Ball
Adjustments U.9 06 and U.9 07 can be used to change a game to 3 or 5
ball play, including the changing of certain features to the recommended 3- and 5-balilevel.
The
Preset Game Adjustments Table for U.S.lCanadian Games lists the adjustments and settings that
comprise the individual groups.
Preset Game Adjustments Table
Adjustment
Adjustment
Install 3-Ball
Install 5 Ball
Number
Description
U.9 07
U.9 06
(factory)
A.101
Balls Per Game
03
05
A.107
Replay Start
4,500,000,000
6,000,000,000
A.206
Lane Extra Ball
10
14
A.207
Attack Wave Extra Ball
02
03
A.210
Attack Wave Difficulty
MEDIUM
HARD
A.211
First Hard Lock
02
01
U.9 08 Install Add-A-Ball
This option deletes all Free Play awards and replaces them with Extra
Ball awards. Individual adjustments are affected, as follows:
Adjustment
Name
A.1 13 Replay Boost
A.1 14 Replay Award
A.1 15 Special Award
A.1 17 Extra Ball Ticket
A.1 19 Match Feature
A.4 04 Champion Credits
A.4 05 High Score 1 Credits
A.4 06 High Score 2 Credits
A.4 08 High Score 3 Credits
A.4 07 High Score 4 Credits
New Setting
Off
Extra Ball
Extra Ball
No
Off
00
00
00
00
00
U.9 09 Install Ticket
This option deletes Credit awards and replaces them with Ticket awards.
Individual adjustments are affected, as follows:
Adjustment
Name
A. 1 14 Replay Award
A.1 15 Special Award
A.1 16 Match Award
A.1 17 Extra Ball Ticket
A.1 31 Ticket Expansion Board
A.4 02 H.S.T.D. Award
New Setting
Ticket
Ticket
Ticket
Yes
Yes
Ticket
1-22
