T.19 Motor Bank Test
This test allows the motor bank to be activated while the state of the
motor bank switches are shown in the display.
This test will continually run the motor bank up and down (with small pauses when a motor bank
switch edge is detected) while the test is running.
Errors are accumulated, and shown in the
display.
If the test accumulates enough errors for the motor bank, the test will stop itself and show the
errors in the display.
During this test, the diagnostic test buttons on the coin door act as follows:
Escape:
Enter:
This button returns to the previous menu.
This button toggles the state of the test from Running to Stopped, or from
Stopped to Running.
T.20 Empty Balls Test
This test kicks out all balls loaded in troughs, lockups, poppers, and
kickouts until no balls remain in those locations.
Note: As the trough kicks out balls, they will stack up in the shooter groove, which may require
manual clearing in order to allow further balls to be kicked out.
1-19
