Coin Door Interface Board
A-20580
c-'-~~~
---'-'i'2;
._~~_:_,7
,:'
---,'1
k;
0 0 0 0 -0
*
0 °_0_:J
5-
0 * ° 0 °
I~
0 0 ° ° ° ° 0
*
0 °
I
'"'--:o:-Tlt=:=========J 3:'
=
J
2
o
°
, 0
°
:
I ~
o
Ii
!j'll
°
I
°
I
~~o
J5
o
000 0 0
J1-1 Orange-Gray, Oed. Sw. Row 8 Form CPU J205-9
J1-2 Orange-Violet, Oed. Sw. Row 7 from CPU J205-8
J1-3 Orange-Blue, Oed. Sw. Row 6 from CPU J205-7
J1-4 Orange-Green, Oed. Sw. Row 5 from CPU J205-6
J1-5 Orange-Yellow, Oed. Sw. Row 4 from CPU J205-4
J1-6 Orange-Black, Oed. Sw. Row 3 from CPU J205-3
J1-7 Orange-Red, Oed. Sw. Row 2 from CPU J205-2
J1-8 Orange-Brown, Oed. Sw. Row 1 from CPU J205-1
J1-9 Key
J1-10 Black, Ground from CPU J205-10
J1-11 Orange-White, Sw. Enable from CPU J205-12
J2-1 Black, Ground from Power Driver Board J141-3
J2-2 Gray-Yellow, +12VAC For Power Driver Bd. J141-2
J2-3 White-Violet, G.I. 6.8VAC from Power Driver J104-1
J2-4 Key
J2-5 Violet, G.I. from Power Driver Bd. J104-3
J2-6 Not Used
J2-7 Black-White from J139-5
J3-1 Green-Brown, Sw. Col., 1 from CPU J212-1
J3-2 Green-Red, Sw. Col. 2 from CPU J212-2
J3-3 White-Brown, Sw. Row 1 from CPU J212-4
J3-4 White-Red, Sw. Row 2 from CPU J212-6
J3-5 White-Orange, Sw. Row 3 from CPU J212-7
J3-6 White-Yellow, Sw. Row 4 from CPU J212-8
J3-7 Key
J3-8 Yellow-Gray, Lamp Col. 8 from Power Driver J122-3
J3-9 Red-Blue, Lamp Row 6 from Power Driver J126-7
J3-10 Red-Violet, Lamp Row 7 from Power Driver J126-8
J3-11 Red-Gray, Lamp Row 8 from Power Driver J126-9
J4 Not Used
J1
,110
1
0°*°0000001
1
:0
O -
m
+>
o
"'
J6
o
000 0 000 0
J5-1 Violet, G.!. Return to Coin Door
J5-2 White-Violet, G.I. 6.8VAC to Coin Door
J5-3 Black, Ground to Coin Door
J5-4 Orange-Brown, Oed. Sw. Row 1 to Coin Door
J5-5 Orange-Red, Oed. Sw. Row 2 to Coin Door
J5-6 Not Used
J5-7 Orange-Green, Oed. Sw. Row 5 to Coin Door
J5-8 Orange-Blue, Oed. Sw. Row 6 to Coin Door
J5-9 Orange-Violet, Oed. Sw. Row 7 to Coin Door
J5-10 Key
J5-11 Orange-Gray, Oed. Sw. Row 8 to Coin Door
J5-12 Green-Red, Sw. Col. 2 to Coin Door Slam Tilt
J5-13 White-Brown, Sw. Row 1 to Coin Door Slam Tilt
J6 Not Used
J7-1 Yellow-Gray, Lamp Col. 8 to Cabinet
J7-2 Red-Blue, Lamp Row 6 to Cabinet
J7-3 Red-Violet, Lamp Row 7 to Cabinet
J7 -4 Red-Gray, Lamp Row 8 to Cabinet
J7-5 Key
J7-6 Green-Brown, Sw. Col. 1 to Cabinet
J7-TGreen-Red,
Sw. Col. 2 to Cabinet
J7-8 White-Orange, Sw. Row 3 to Cabinet
J7 -9 Not Used
J7-10 White-Brown, Sw. Row 1 to Cabinet
J7-11 White-Orange, Sw. Row 3 to Cabinet
J8-1 White, Sw. Row to Cabinet Slam Tilt
J8-2 Key
J8-3 Green, Sw. Col. to Cabinet Slam Tilt
J9-1 White-Yellow, Sw. Row 4 to Plumb Bob Tilt
J9-2 Key
J9-3 Green-Brown, Sw. Col. 1 to Plumb Bob Tilt
J9-4 White-Red, Sw. Row 2 to Interlock Sw.
J9-5 Green-Red, Sw. Col. 2 to Interlock Sw.
