Page 69 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

Oplo Assemblies and Locations
Opto LED Assembly
A-16908
Part Number
Description
A-14231
5671-12731-00
5768-13155-02
03-8506-1
4104-01001-06
LED Assembly
LED Diode Infra Red
PCB Single IR LED (Green Mask)
White Mounting Base
SMS #4 x 3/8 P-PH-A
Crea Judge TwiZ
Pop
Part No.
Description
20018 20020 50020 50022
Game and Part Quantity
A-15769
Right Ball Popper Assembly
1
A-15769-1
Upper Righi Ball Popper Ass'y
1
A-15842
Lower Right Ball Popper Ass'y
1
A-16058
Wire Chute Assembly
1
A-16062
steel Center Ramp Assembly
1
A-16170
steel Lockup Trough Ass'y
2
A-163l2
GumbaU Popper Assembly
1
A-16326
Ball Guide, Mini Playfield
1
A-16518
Ball Guide, Mini Playfield
1
A-16580
Left Ball Popper Assembly
1
A-16796
Large Ball Guide Assembly
2
A-17l32
Bottom Wire Ramp
1
A-17170
Left Plastic Ramp Assembly
2
A-171n
Center Plastic Ramp Ass'y
2
A-17l
eo
Left Ball Popper Assembly
1
A-17231
Main Plastic Ramp Assembly
3
A-17247
Lifter Assembly
1
A-17258
Right Ball Popper Assembly
1
A-17402
Wheel Drop Guide Assembly
1
A-17403
Right Exit Ramp, Upper Plfd
1
A-17n4
Kicker Coil Assembly
1
