Unique Assemblies - cont'd
WHO?OUNNIT (50044)
Disappearing Post Assembly
A-17932
Item Part Number
Description
1 01-12441
Diverter Post Bracket
2 03-7067-5
Coil Tubing
3 01-8-508-T
Coil Retainer Bracket
4 AE-27-1200
Coil Sub-Assembly
5
10-135
Spring
6 A-17986
Be" 'Armature Assembly
7 23-6420
Rubber Grommet
8 4008-01 017-04 Mach. Screw, #8-32
x
1/4"
J
@
rJ
<,
•.••.•......
,
,
,,
~
12
Motor & Bracket Assembly
A-20483
Item Part Number
Description
04-10226
04-10080
14-8026
01-8600
4002-01105-07
4010-01007-16
4008-01 041-04
4008-01083-04
5070-09054-00
5647-12693-06
H-20565
H-18600-1
Motor Mounting Bracket
Motor Cam Assembly
3-Bank Target Motor
Insulator (2)
Mach. Screw, 2-56
x
7/16
H
(4)
Mach. Screw, 10-32
x
1" (2)
Mach. Screw. 8-32
x
1/4" (4)
Sel Screw, 8-32
x
1/4"
Diode
1N4004,
1.0Amp
(2)
Sub Miniature Switch
Cable
Cable
1
2
3
4
5
6
7
8
9
10
11
12
(jJafPLt
/MIDWAY
5-107
