Unique Assemblies - cont'd
WORLD CUP SOCCER (50031)
7
Mini Playfield Assembly
A-18222
Item Part Number
Description
Item Part Number
Description
1.
36-50031-1
Hard Coat Mini-Playfield
9.
5070-09054-00 Diode 1N4004
2.
20-9247
Coil Magnet
10.
4002-01105-06 Mach. Screw, 2-56 x 3/8'
3.
A-18157
Magnet Bracket & Pole Piece
11.
4808-0 1175-08 E·P #8 x
1/2
IND. PL-HWH
4.
12-7195.1
Wire 8all Guide
12.
03-7655-4
Cable Clamp,
1/4'
5.
5647-12693-59 Switch
13.
20-9672
Wave Spring Washer
6.
A-18226
Switch 8all Guide Assembly
14.
01-13063
Shield, Mini-Playfield Switch
7.
H-18205
Switch Cable
15.
03-7520-2
Tie Wrap, Nylon
3-7/8
8.
17-1116-2
Jumper Wire Cut. 2'
16 .
03-9t89-3
Mylar
(jJ~/MIDWAY
5-73
