Page 489 - BallyMidway GREY Parts Catalog 16-9562-A

Unique Assemblies - cont'd
WORLD CUP SOCCER (50031)
SIDE VIEW BACK VIEW FRONT VIEW
Goalie Unit Assembly
A-17741
Item Part No. Description Item Part No. Description
1. 14-7997 Motor 14. 4700-00033-00 Flatwasher, 17/64 x 3/4 x 15ga.
2. 4008-01003-12 Mach. Screw, 8-32 x 3/4' 15. 4008-01083-08 Set Screw, #8-32 x 1/2"
3. A-17780.1 Mtr. Bracket Assembly 16. 10-362 Spring
4. A-17744 Crank Assembly 17. A-17779 Target Switch Assembly
5. A-17782.1 Drive Assembly 18. 20-8712-25 'E' Ring, 1/4' Shaft
6. A-17743 Target Assembly 19. H-18204 Opto Cable Assembly
7. 01-12333.1 Goalie Oplo Bracket 20. 4008-01168-06 Mach. Screw, #8-32 x 318'
8. 03-8523 Insulator, 314 x 1-1/4' 21. 4408-01119-01 Nul #8-32 ESN
9. 03-9134 Goalie Plastic 22. 4005-01003-12 Mach. Screw, #5-40 x 3/4'
10. H-18214-1 Switch Cable Assembly 23. 01-12823 Nut Plate
11. A-16909 Photo Transistor Assembly 24. 03-7520·2 Tie Wrap
12. A-1690B LED Assembly 25. *31-1924-7 Decal
13. 4106-01013-06 Sh. Metal Screw, #6 x 3/8' 26. H-18600-4 Cable
• Not available for individual sale. Order Decal Set 31-1924.
