Unique Assemblies - cont'd
WORLD CUP SOCCER (50031)
o
Ball Gate Actuator Coil Assembly
A-17796
Item Part No.
Description
1.
2.
3.
4.
5.
6.
7.
8.
9.
01-12348
A-14406
A-11146
A-6892
10-120
4701-00003-00
4700-00089-00
4008-01021-07
10-194
Bail Gate Coli Bracket
Coil Assembly
Armature Assembly
Frame & Eyelet Assembly
Spring
Lockwasher, #8 Split
Flatwasher, 11/64 x 7/16 x 16ga,
Mach, Screw, 8-32 x
7/16'
Extension Spring
Motor Assembly
A-17569
Item Part No.
Description
1 .
2,
3.
4.
5.
01-12175.1
14-7996.1
4008-01168-10
20-8712-25
H-18601-6
Motor Mount Bracket
Motor - Soccer 8all
Mach. Screw, 8-32 x 3/4'
"E'-Ring, 1/4" Shaft
Cable Assembly
Associated Assemblies:
6.
A-17568
a)
A-17641
b)
02-4904
7.
23-6709
Plate Assembly
Guide, Plate
Post, Plate
Soccer Ball
(jJafPLt
/MIDWAY
5-69
