Page 484 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

Unique Assemblies - cont'd
INDIANAPOLIS 500 (50026)
19
f.
-8-----·
--1.
i
l
L_
_J
Race Track Assembly
A-20169
Item Part Number
Description
Item Part Number
Description
1 04·10079.1
Race Track Weldment
11 4004-01003-03 Mach. Screw, 4-40 x 3116"
2 04-10082
Car Bracket & Hub Weldment
12 H-20185
Cable
3 04-10094
Reflector Socket Assembly
13 03-7655-4
Cable Clamp, 1/4"
4 14-8022
Race Track Gear Motor
14 03-7520-2
Tie Wrap, Nylon 3-7/8"
5
01-13640
Car Mounting Bracket
15 4006-01113-06 Mach. Screw, 6-32 x 318"
6 04-10208
Car & Driver Assembly, Small
16 17-1116-2
Wire, Yellow Jumper Cut 2"
7 4010-01186-04 Set Screw, 10-32 x 1/4"
17 03-9408
Cover - Racetrack
8 4008-01113-08 Mach. Screw, 8-32 x 1/2"
18 31-2505-1
Decal - Racetrack
9 4006-01113-18 Mach. Screw, 6-32 x 1-1/8"
19 20-9682-1
Protective Sleeve
10 4406-01119-00 Nut 6-32 ESNA
