Unique Assemblies - cont'd
POP EYE SAVES THE EARTH (50022)
Mini-Playfield Assembly
50022-PL-UP
Item Part Number
Description
Ilem Part Number
Description
1 A·11905
Socket & Bulb Ass'y (8)
32 02-4659--1
Post
#
10, 3/8 Deep MS Top (6)
2 A·12753-2
Lug & Diode Ass'y (3)
33 03-7520-2
Nylon Ty-Rap 3-7/S"
3 A-16976-R Flipper Assembly, Right
34 03-7655-4
Cable Clamp 1/4" (2)
4 A-16976-L-1 Flipper Assembly, Lett
35 03-7655-8
Cable Clamp
1/2" (7)
5
A-17226-4
Station Target Ass'y, Red (2)
36 03-8319-10
Star Post #S, Tr Blue
6 A-17403
Upper Right Exit Assembly
37 03-8371
Spacer Spool #8 (5)
7 A-17462
Upper Level Ramp Ass'y
38 03-8947
Upper Level Window
8 A-17626-4
Playfield Plastic Assembly
39 17-1116-4
Jumper Wire 4" (6)
9 A-H626-8
Playfield Plastic Assembly
40 17-1116-5
Jumper Wire 5" (2)
10 A-17647
Light Cover Assembly
41 17-1116-11
Jumper Wire 11" (2)
11 A-17648
Left Cover Assembly
42 20-9732-5
Small Flipper w/Shaft, White (2)
12 A-17649
Right Cover Assembly
43 23-6300
Rubber Ring
5/16",
White
13 A-17736
Upper Lett Exit Ramp Ass'y
44 23-6535
Rubber Bumper Grommet (5)
14 A-17769
Upper Ramp Deflector Ass'y
45 23-6552
Bumper Sleeve, Yellow (6)
15 A-17802
Socket & Bulb Ass'y (2)
46 23-6553-4
Small Flipper Ring, Red (2)
16 A-17813
Rollover Switch Ass'y
47 23-6556
Bumper Sleeve, Black (2)
17 A-17813-1
Rollover Switch Ass'y
48 31-1878-10
Playfield Plastic
18 A-H817
Light & Bracket Assembly
49 36-50022-1
Mini-Playfield Hardcoat
19 A-17826
Socket & Bulb Ass'y (4)
50 4006-01027-06 MS 6-32 x
3/8
P-RWH (4)
20 A-1783S
Socket & Bulb wlDiode (2)
51 4006-01113-06 MS 6-32 x
3/8
PL-HWH (6)
21 A-17836
Socket & Bulb w/Diode
52 4008-01005-04 MS 8-32 x 1/4 (P-PH)
22 A-17838
#8 Stud Bracket Ass'y (5)
53 4104-01042-06 SMS #4X 3/8 P-FH (4)
23 A-17881
Opto Brackets & Cable Ass'y
54 4104-01042-OS SMS #4 x
1/2
P-FH-A (7)
24 H-17585-3
Mini-Playfield Cable Ass'y
55 4106-01033-OS SMS #6 x
1/2
P-TH-A (5)
25 01-11815
Ball Guide
56 4406-01119-00 Nut 6-32 ESN (8)
26 01-11816
Ball Guide
57 4408-01119-01 Nut 8-32 ESNNNtm (6)
27 01-12171
Ball Guide
58 4410-01132-01 Nut 10-32 ESNNNtm (10)
28 01-12173
Ball Guide
59 4700-00021-00 FW .203 x .437 x .032 (16)
29 01-12305
Ball Guide
60 4808-0117S-07Y EP#8x7/161nd PL-HWH-Yel (33)
30 01-12587
Ball Guide
61 4808-01175-08 EP#8x1/21nd PL-HWH (50)
31 02-4426-1
PF #8 WS 6-32 Top (6)
5-58
